HCS03.1E-W0210-A-05-NNBV

Name: HCS03.1E-W0210-A-05-NNBV
Brand: Bosch Rexroth Indramat
Price: 462 USD
Availability: InStock
Rating: 4.4 (26 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

MPN: R911308415

Unused Original Box Pricing Available!

In-Stock, Ships Today

Current response time:

6 Minutes 15 Seconds

The HCS03.1E-W0210-A-05-NNBV Compact Converter is manufactured by Rexroth Indramat Bosch. This converter has an Internal Air cooling mode and a 210A Maximum Current. This compact converter also comes with a 400?500V Connection Voltage.

Preparing your secure checkout page...

Description
Revisions
Specs
FAQ

Product Description

This compact converter from Bosch Rexroth is a quality item build for your machines. The converter is a great pick for use in packaging machines, handling systems, food machines, mounting systems, machine tools, paper processing machines, and printing machines. Make note of the operating specifications and recommendations as set forth by the manufacturer prior to purchasing this converter. This ensures the longevity of the converter as well as the lifetime of the equipment (your equipment) where the component will be installed.

The HCS03.1E-W0210-A-05-NNBV is a compact converter from the HCS series from Bosch Rexroth. This converter provides 3 x AC 400 to 500 V + 10%, -15% mains connection voltage. This converter features a line of 11 to 75 kW with an infeeding power supply and is cooled internally by air by way of an integrated blower. The blower is temperature dependent and activates automatically when necessary. The converter has a maximum current of 210 A and its degree of protection is IP 20. The converter is powered by a DC 24 V power supply from external or from DC bus. There is a braking transistor integrated into the converter’s design.

Once you use this drive controller in the specified manner you will be prolonging the life of the device, increasing cost efficiency for yourself. By using the device in the correct manner, you also save on maintenance costs and will end up prolonging the life of your equipment. Ensure you use the converter within the operating conditions as specified by the manufacturer. It is very important not to operate in any way that will constitute “inappropriate use” when installing your HCS03.1E-W0210-A-05-NNBV part.

HCS03.1E-W0210-A-05-NNBV Technical Specifications

Connection Voltage:	400?500V
Permissible ambient temperature range:	0 to 450C
Maximum current:	210A
Degree of protection :	IP20
installation altitude with nominal data?:	1000 meters above sea level.
Climatic category:	3K3 according to IEC721
Nominal motor power :	75KW
connected laod:	99.3kVA
Mains input continuous current:	146A
Control voltage :	24V

Frequently Asked Questions about HCS03.1E-W0210-A-05-NNBV

Q: Can the HCS03.1E-W0210-A-05-NNBV maintain operational efficiency above 1000 meters?

A: The HCS03.1E-W0210-A-05-NNBV can be installed and operated at an hieght as high as 4000 meters above sea level. However if the converter is to be used above 2000 meters, an overvoltage limiter for tansient overvoltage must be installed in the installation or building.

Q: How compatible is the HCS03.1E-W0210-A-05-NNBV with foreign materials?

A: The HCS03.1E-W0210-A-05-NNBV is developed to be compatible with a wide range of foreign materials (eg cleaning agents and lubricants). However since it is impossible to follow the production of new materials, operators must carry out a compatibility test for new lubricants, cleaning agents and other foriegn materials.

Q: Is the HCS03.1E-W0210-A-05-NNBV environmentally friendly?

A: The HCS03.1E-W0210-A-05-NNBV does not contain any harzadours substances that can relase in the case of appropriate use. Under normal operation, the controller does not have any negative effect on the environment.

Q: Can the HCS03.1E-W0210-A-05-NNBV be directly installed without a control cabinet?

A: The installation of the HCS03.1E-W0210-A-05-NNBV should be done in an additional control cabinet that meets the IP54 protection class. The housing of the of the controller will only provide protection against large foreign solid substances.

Q: What is the installation appropriate condition for the HCS03.1E-W0210-A-05-NNBV?

A: The HCS03.1E-W0210-A-05-NNBV should be installed at an ambient temperature that falls between 0 to 40 degree celsius. The controller should also be kept away from extreme vibration and water condensation.
