HCS01.1E-W0028-A-03-B-ET-EC-NN-NN-NN-FW

Name: HCS01.1E-W0028-A-03-B-ET-EC-NN-NN-NN-FW
Brand: Bosch Rexroth Indramat
Price: 356 USD
Availability: InStock
Rating: 4.5 (11 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

MPN: R911325248

Unused Original Box Pricing Available!

In-Stock, Ships 1-2 Days

Current response time:

3 Minutes 20 Seconds

The Bosch Rexroth HCS01.1E-W0028-A-03-B-ET-EC-NN-NN-NN-FW compact converter operates with a continuous current of 11.5 A, offers a power range of up to 9.7 kW, and supports multi-Ethernet communication for seamless integration.

Preparing your secure checkout page...

Description
Revisions
Specs
FAQ

Product Description

The HCS01.1E-W0028-A-03-B-ET-EC-NN-NN-NN-FW Compact Converter by Bosch Rexroth is a high-performance solution for industrial automation. Known for its advanced engineering and reliable performance, Bosch Rexroth provides automation products designed to meet demanding operational requirements. This compact converter is ideal for space-saving installations that feature multi-Ethernet communication and integrated safety with Safe Torque Off (STO) functionality.

The HCS01.1E-W0028-A-03-B-ET-EC-NN-NN-NN-FW converter operates with a continuous current of 11.5 A. It has a maximum current of 28 A and delivers consistent performance under heavy loads. It offers power ranges of up to 6.2 kW without a main choke and 9.7 kW with a main choke ensuring flexibility for different power requirements. The voltage range is versatile handling inputs from 110 V to 500 V AC and providing output voltages up to 500 V. The converter supports switching frequencies of 8 kHz, 12 kHz, and 16 kHz. It allows for fine-tuned control over motor operations that achieve output frequencies of up to 1600 Hz. This range of frequencies offers precise control in dynamic systems requiring quick response times. Its overload capacity is designed to manage higher current demands making it suitable for heavy-duty applications where reliability is critical.

The HCS01.1E-W0028-A-03-B-ET-EC-NN-NN-NN-FW converter measures 70 mm in width, 220 mm in height, and 268 mm in depth. This makes it a perfect choice for installations where space is limited. Weighing approximately 2.13 kg, it is lightweight yet robust enough to handle demanding tasks. The protection rating of IP20 ensures the converter is appropriate for indoor installations, though it is not resistant to dust or water exposure. The integrated Safe Torque Off (STO) enhances operator safety by preventing unintended motor movements during shutdowns. This converter supports high-performance operations with seamless integration.

HCS01.1E-W0028-A-03-B-ET-EC-NN-NN-NN-FW Technical Specifications

Continuous Current:	11.5 A
Protection Rating:	IP20
Maximum Current:	28 A
Power Range Without Main Choke:	Up to 6.2 kW
Power Range With Main Choke:	Up to 9.7 kW
Voltage Range Input:	110 V to 500 V AC
Voltage Range Output:	Up to 500 V
Switching Frequencies:	8 kHz, 12 kHz, 16 kHz
Output Frequencies:	Up to 1600 Hz
Weight:	2.13 kg

Frequently Asked Questions about HCS01.1E-W0028-A-03-B-ET-EC-NN-NN-NN-FW

Q: How does the HCS01.1E-W0028 converter's overload capacity enhance performance?

A: The Bosch Rexroth HCS01.1E-W0028-A-03-B-ET-EC-NN-NN-NN-FW converter's overload capacity supports higher current demands during peak loads. This ensures consistent, reliable operation in heavy-duty applications.

Q: Why does the converter offer switching frequencies up to 16 kHz?

A: The HCS01.1E-W0028-A-03-B-ET-EC-NN-NN-NN-FW supports high switching frequencies to provide precise motor control. This is crucial for dynamic systems requiring rapid response.

Q: What is the benefit of the converter's IP20 protection rating?

A: The HCS01.1E-W0028-A-03-B-ET-EC-NN-NN-NN-FW converter's IP20 rating ensures suitability for indoor installations. It offers basic protection but isn't resistant to dust or water.

Q: How does multi-Ethernet communication benefit this converter?

A: The HCS01.1E-W0028-A-03-B-ET-EC-NN-NN-NN-FW supports multi-Ethernet protocols, enabling seamless integration with diverse automation systems. This provides flexibility for various industrial applications.

Q: Why is Safe Torque Off (STO) critical for this converter?

A: The integrated STO function in the HCS01.1E-W0028-A-03-B-ET-EC-NN-NN-NN-FW enhances safety by preventing unintended motor operation. This feature is vital for protecting personnel during system shutdowns.

Internal Product Review

‘‘The Bosch Rexroth HCS01.1E-W0028-A-03-B-ET-EC-NN-NN-NN-FW converter is an excellent choice for industrial automation with its wide input voltage range (110-500 V AC), overload capacity, and compact design. Integrated Safe Torque Off (STO) enhances safety, while its robust 28 A peak current rating ensures reliable performance.’’
