Product Description

The FCS01.1E-W0005-A-04-NNBV Bosch Rexroth frequency converter and its associated motor must be dimensioned according to the supply voltage. This product makes use of standard mains fuses and a main contactor or switch at the power input side. The device can be operated with IT mains after the required adjustments are made using jumpers. It is connected to the motor through the U, V, and W terminals with the help of an unshielded cable of a maximum 100m length or a 30m shielded cable. The braking resistor fitted to the unit becomes hot during operation. This resistor may get damaged due to an incorrect connection.

The converter supports the DC coupling mechanism if the drives in its drive system work simultaneously in a regenerative manner. This product features an IP 20 degree of protection. The device encompasses an internal 24VDC voltage supply. The unit has a ramp time of 0 to 320 seconds. Its control connectors can be opened by means of a small screwdriver. The green LED of this converter represents the application of mains voltage when it is in use. The LED flashes rapidly when the output is overloaded. The product supports adjustments for multiple requirements by using various modules for parameterization, control, and indication.

The frequency converter features an external connection to its function module so that the module is easily accessible. This module must be fitted only after turning OFF the mains voltage and waiting for the specified period. The device shows the active parameter record on the LED display of its control panel. The unit has an analog setpoint value constancy of less than 1%. It is intended to be operated between 0°Cand 40°C with rated data. The product has a waiting period of 60 seconds between two mains activation cycles. The frequency converter with a one-year Wake Industrial warranty can be shipped to any address worldwide.
