DMA 15A 1101-D

Product Description

The DMA 15A 1101-D three-phase modular inverter is listed among the DM product group of such inverters manufactured by Bosch Rexroth. This product comes with a regulated DC link voltage rating of 670VDC. The device comes integrated with mechanics for backplane modules. It is to be fitted inside a closed switch cabinet with at least IP 54 degree of protection. This unit must be fitted in the vertical orientation. The module incorporates an air-cooling mechanism for its backplane mechanics. The product is designed to be in adherence with the requirements of EMC 93/68/EEC, 89/336/EEC, and 93/44/EEC directives. The device is intended for operation in industrial environments. It comes with a warranty backup for a year.

The machine in which the inverter is installed should meet the required EMC as well as machinery directives. This product must be properly installed, erected, transported, and stored for effective operation. The device features a factory set 8kHz switching frequency. It incorporates an RMA/DM 30 type backplane module with a single fan. The unit has a maximum current of 15A at 2kHz. The inverter features supply and axis modules. The product supports a direct power supply connection and can be connected to the backplane module directly through a plug-in action.

This standard device supports a SERCOS interface along with a standard encoder interface. The SERCOS interface comprises a 32-bit signal processor on a processor board and optical fibers. The unit operates with derated data between a temperature range of 46°C and 55°C. It can be put to use with the manufacturer’s SR and SF series of servomotors, synchronous linear motors, and DU series of asynchronous motors. The device supports the position, speed, and interpolation interfaces.  This inverter is one of the several Servodyn D range of such modules. The DMA 15A 1101-D can be dispatched safely to any global address through reputed shipping agents such as FedEx.
