Product Description
Indramat is a reliable manufacturer of machines, equipment, and devices that are used in different fields and industries. The DKS 1 Intelligent Digital Servo Drive with Integrated Power Supply - Basic Unit is one of its outstanding products.
The DKS01.1-W050A-RS01-03-FW has efficient performance features and easy to service parts. The servo drive can be directly connected to a three-phase power source with 230 V. A power shutoff serves as its protection system while the drive’s integral dynamic braking system enables deceleration during an electric circuitry malfunction. Applications and operation modes can be specified through the installation of various plug-in modules on the DgKS01.1-W050A-RS01-03-FW. Different command interface cards are available such as the SERCOS interface, the ANALOG interface with incremental encoder emulator, the ANALOG interface with absolute-value encoder emulator, and the single-axis positioning card which can enable the servo drive to achieve single-axis position control. The software module that stores the operating software and the parameters can be reused in case of hardware replacement.
The motor type to be used for the DKS01.1-W050A-RS01-03-FW is the MDD AC servo motor. According to the technical data available, the DKS01.1-W050A-RS01-03-FW has a rated current of 50 A while its peak current is 50 A. It has a continuous current of 25 A. The servo drive’s input voltage is 3x 230 (±10%) V while its frequency is 50…60 Hz. All DKS 1 servo drives have an internal bus DC voltage of 300 V. When it comes to connecting the servo drive to the motor, it is recommended that Indramat’s power cables should be used. The maximum length of an Indramat cable is 75 meters. For the grounding requirements of the servo drive’s electrical power system, an isolation transformer is not necessary. This unit can be shipped globally with a one-year warranty period from Wake Industrial.
