DKR03.1-W200N-BA08-01-FW

Product Description

The Rexroth DKR03.1-W200N-BA08-01-FW is a drive controller. It is designed for industrial applications where control of electrical motors and their monitoring is required. The drive controller needs to be properly parameterized for the connected motor to perform its desired operation. Applications for DKR controllers include NC machine tools and printing machines. Motors which are compatible with the DKR03.1-W200N-BA08-01-FW include 2AD or ADP spindle motors, LSF and LAF linear motors and 1MB frameless spindle motors. DKR drive controllers can manage motors rated between 10 and 93 kilowatts of continuous power output. Input of the DKR03.1-W200N-BA08-01-FW controller is designed for 3–phase AC input between 400 and 480 Volts AC. The controllers included an integrated mains contactor and an emergency shutdown device. DKR03 controllers such as the DKR03.1-W200N-BA08-01-FW can be ordered with integrated brake resistor.

The DKR03.1-W200N-BA08-01-FW is rated for 200 Amps. The drive controller does not include a bleeder. Integrated features available on the controller include blower for cooling, digital servo and resolver feedback and an analog command communication interface. Numeric code of the drive controller is 08 and the version numeric code is 01. The firmware for the controller needs to be ordered separately. The line frequency for the input voltages which are supported by the DKR03.1-W200N-BA08-01-FW range from 50 to 60 Hertz. The control voltage is 230 Volts AC with 10% allowed tolerance and the control voltage power is 200 VA. When tact frequency of the power section is 4 kilohertz the continuous current of the drive is 92 Amps and when the tact frequency is 8 kilohertz the continuous current of the drive is 78 Amps. Peak current rating of the drive is 141 Amps. This unit can be shipped globally with a one-year warranty period from Wake Industrial.
