Product Description
The DKR03.1-W200B-BE79-01-FW is a digitally integrated controller for main spindle motors with linear motors and 1MB frameless spindle motors. The drive controller has an integrated emergency stop shutdown for power breakage. The drive's rated power is 3*AC 400-480,+/-10%, and current-voltage is 200 A. It comes with the control voltage of AC230V, +/-10%. The continuous current of drives has 4 kHz: 92, and the drive's peak current is 141A. The drive controller has high control and broad speed range aspects with a constant power supply.
The DKR03.1 spindle drive is suitable for printing machines as well as NC-controlled machine tools. The DKR03.1-BE79 is designed for grounded direct connection and emergency stop shutdown device. Various means and modules can be adapted to configure the drive controller, such as a mounted measuring encoder. It has an optional brake resistor that requires 150KWs braking energy. The basic unit has no additional plugins cards, but the firmware module has a modified setting as it is the operating software of the digital drive. The central drive controller is configured by many interfaces such as an auxiliary plugin module, a Basic unit, a command interface card, and a software module.
The spindle drive has built-in cooling blowers. The machine's cooling has different variances; it can be cooled with air inside the control enclosure and outside the square or cool the drive by using a cooling duct. The DKR03.1 auxiliary plugin has different variants. It has digital I/Os for bidirectional data exchange, measuring system, analog signal interface, and CLC link interface. The spindle drive has IP 20 per EN60529/IEC529 protection category. The drive's ambient temperature is from +5°C to +45°C, and installation elevation is from 0 to 1000 m above sea level. This unit can be shipped globally with a one-year warranty period from Wake Industrial.
