Product Description
The DKR03.1-W100N-BE37-01-FW is a drive controller which belongs to the Bosch Rexroth DKR series of drive controllers. These controllers are meant to digitally control Rexroth Indramat motors. The controller can be configured easily by using appropriate card modules. The documentation should be referred while installing the drive controller and care should be taken to stick to the instructions given. This controller offers protection rating of IP 20 according to IEC 529/ EN 60529 standards. The line code of DKR03.1-W100N-BE37-01-FW is 03. This drive controller finds application in printing industry and machining tools. We ship this drive controller all over the world through our tested delivery partners.
Take care to operate this drive controller between an ambient temperature range of 5°C and 45°C. Make sure the application it is used in is in line with national EMC regulations. It takes at least 5 minutes for the capacitors in the device to discharge after the device has been switched off. This drive controller model uses a SERCOS interface for communicating commands. Be aware that if wrong or unclean cable connections are used, it can make the controller go through dangerous movements. This can occur anytime during the operation.
Make sure to install an emergency stop circuit with the power connection of the controller to avoid unplanned start-up. Please use a master switch to make sure that the drive controller is disconnected while repair and maintenance operations. The peak current rating of the controller is 71A. The unit cools down through natural convection with an integrated air blower. Please allow the unit to cool down for at least 10 minutes after switching off, before handling it. It operates on an input current of 50 to 60 Hz. It gives off a total of 1200 Watts of heat. This unit can be shipped globally with a one-year warranty period from Wake Industrial.
