Product Description
The DKR02.1-W300Z-B drive controller manufactured by Bosch Rexroth features a 2 line code. This controller is designed to be mounted inside a closed housing or a control cabinet in accordance with DIN VDE 0160 specifications. This product has a shock resistance of 8.4g for 5 seconds and 4.2g for 10 seconds because of the inbuilt contactor. This device is meant to be operated between an ambient temperature range of 5°C and 45°C with rated data. When the controller is installed inside the control cabinet, safety guidelines must be considered to protect against contact.
This drive controller dissipates energy during operation through the inbuilt heatsink and air vents above the housing. The controller has a maximum pressure rating of 160Pa. The product is cooled by air circulation through the built-in blower. The motor associated with this device implements a digital servo and resolver feedback. The unit should be always mounted in the vertical direction to avoid damage. There must be a minimum clearance of 160mm above and below the controller inside the closed housing for air circulation. The product is equipped with a motor power connection as well as the connection for monitoring the temperature of the motor at its top.
This controller comprises two control inputs that can be connected to its X9 connector. The drive tends to fail or malfunction if its power supply lead is fitted with a FI current limiting circuit breaker. It supports direct connection to external conductor three-phase systems or grounded star systems. The drive controller supports connection to ungrounded three-phase systems via an isolating transformer. The main fuse rating of the product depends on the continuous power of the connected motor. The drive controller has a one-year warranty backing and can be sent globally to the address of your choice.
