Product Description
The DKR02.1-W300N-BE11-01-FW drive controller manufactured by Bosch Rexroth features an S1 reset key and two control inputs on its X9 connector. The product can be connected to a PC or a VT-100 terminal through its RS-232 interface. The device encompasses more protection with an isolating transformer than with an overvoltage suppressor when its connection is done to three-phase systems. Its Bb1 contact must not be overloaded to ensure that it is not damaged. The motor feedback connection must be established using only the manufacturer’s feedback cable assembly. The vertical axes of its drives must be either balanced or mechanically secured to prevent them from falling off.
This drive controller and its drives have to be checked that they are in standstill mode before entering the danger zone. The controller can operate at a maximum temperature of 55°C. The load factors of the product have to be taken into consideration when it functions outside the ambient temperature. The device can be installed at an elevation of 1,000m over sea level. The drive has a peak current rating of 212A. It weighs approximately 104kg. The controller is equipped with a continuous regenerated power of nearly 43kW. The DKR02.1-W300N-BE11-01-FW can be delivered to you through any reputed freight carriers.
The drive supports a continuous power of nearly 55kW at 4kHz and 43kW at 8kHz. The ideal storage and transportation temperature of the controller is between -30°C and 80°C. The rated data gets decreased by 80% when the ambient operating temperature is exceeded. Its M1-RAC accessories kit weighs 1.7kg. The power connection to its drive is isolated using a start-inhibit system or an emergency stop circuit so that no unplanned startup takes place. The regenerated braking energy of the controller is once again supplied to the mains. The drive controller comes with a warranty for one year.
