Product Description
The DKR02.1-W300B-BE32-01-FW is a 200-VA compact drive controller from Bosch Rexroth. This unit offers a digital, intelligently and precise control of ADF/2AD Alternating Current main spindle motors, 1MB frameless motors and LAF/LSF linear motors. Generally, the electric motors to be controlled by the DKR02.1-W300B-BE32-01-FW have a continuous output shaft power of 10 – 93 kW. Its current rating is 300 Amps.
The DKR02.1-W300B-BE32-01-FW has 5 module slots for enabling the pairing of plug-in cards. These plug-in cards include aux. cards, command interface cards and a software module. It utilizes an OS that is loaded on to the DSM software module as EPROMs. If need be, the OS can also be preloaded on an auxiliary plug-in card. The DKR02.1-W300B-BE32-01-FW utilizes a SERCOS command interface for effective communications. It features a resolver/digital servo feedback mechanism for optimum operations. Airflow into the control cabinet of the DKR02.1-W300B-BE32-01-FW has a volume flow rate of 300 m3/hour and a maximum pressure of 0.16 kN/m2.
The DKR02.1-W300B-BE32-01-FW has power rating values that have been carefully selected to achieve precise and efficient control of corresponding servo motors. By design, the heat loss mechanism of the DKR02.1-W300B-BE32-01-FW is achieved by convection and facilitated by an in-built blower and heatsink unit. The internal and external energy dissipation factor of this unit is a function of the load it is subjected to. By design, the DKR02.1-W300B-BE32-01-FW is designed to be cooled by internally generated air, heat withdrawal can also be achieved via duct cooling and external air, depending on the operational requirements. The DKR02.1-W300B-BE32-01-FW comes fitted with an integrated bleeder. The function numeric code of this model is 56, and its version function numeric code is 01. This unit can be shipped globally with a one-year warranty period from Wake Industrial.
