Product Description
The DKR02.1-W300B-BE12-01-FW drive controller offered by Bosch Rexroth is operated with the manufacturer’s 2AD, ADF, 1MB, LSF or LAF series of motors. The controller can function at a maximum temperature of 55°C with data deration up to 80%. The product supports a maximum installation elevation of 1,000m above sea level. The device is manufactured with a protection category of IP 20 as per IEC 529 / EN 60529 specifications. Its storage should be done in a shock-free place that is free of dust and moisture. The unit is meant to be transported by means of shock-damped supports if there is a possibility of excessive shock during transport.
The controller has a function numeric code of 12. This product features continuous current ratings of 141A and 110A respectively at 4Hz and 8Hz frequencies respectively. The device is designed to be stored and transported between -30°C and 80°C. Its plug-in modules must be stored and transported in a packaging that can conduct electrostatic loads. The two rating plates not only help to identify the basic unit and plug-in modules but also procure spare parts when there is a malfunction. The term COVER on the rating plate of the product indicates that there is no plug-in module in that slot. The drive is connected to a control unit of a higher rank using fiber optic cables.
The drive may show signs of malfunctioning in case the interference voltage gets coupled. The product depicts a power voltage of 0 to 380 volts and continuous regenerated power of around 43kW. This device can be connected to signal voltages as its X8 connector for measuring and test purposes. The X9 connector of the unit incorporates the two ON and OFF control inputs. The motor power connection and mains connection are present at the top of the controller. The DKR02.1-W300B-BE12-01-FW controller can be dispatched through delivery agents with a warranty that is valid for a year.
