DKR02.1-W300B

Name: DKR02.1-W300B
Brand: Bosch Rexroth Indramat
Price: 341 USD
Availability: InStock
Rating: 4.3 (11 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

MPN: R911287698

In-Stock, Ships Today

Current response time:

6 Minutes 6 Seconds

The DKR02.1-W300B is a modular drive controller designed by Bosch Rexroth Indramat. The controller carries out intelligent motor control. It is particularly suited for LSF or LAF linear motors, 1 MB frameless spindle motoes, and the 2AD or ADF a.c main spindle motors.

Preparing your secure checkout page...

Description
Specs
FAQ

Product Description

Bosch Rexroth is an internationally renowned producer and distributor of revolutionary industrial drive and control technologies. With more than 35 years of excellence, the company now stands at the forefront of industrial automation and can now boast of hundreds of cost-efficient products that are widely used in various industries all over the world. The DKR02.1-W300B is a sophisticated drive controller produced by the company, the controller is designed to carry out the intelligent control of Rexroth Indramat motor designs specifically the 2AD or ADF spindle motors, the 1MB frameless spindle motor and the LSF or LAF linear motor. This industrial controller is designed according to American can European Quality stand safety standards, it features a modular design and can be easily configured to meet the operational requirements of a wide range of industrial applications. The DKR02.1-W300B industrial drive controller is popular for its ability to provide a high level of control and a broad speed range with constant power. The controller is designed for direct mains connection to grounded AC mains with a supply voltage that falls between 3× AC 400 to 480 V, it is also equipped with an integrated mains contactor and an emergency stop shutdown device. An integrated brake resistor is also present in the DKR02.1-W300B drive controller, this resistor allows for the smooth decelerating of the drive even if the mains supply fails. The heat generated by the DKR02.1-W300B industrial controller is regulated through the combined operation of the heatsink and air blower which are already integrated into the housing of the device. However it is still important for operators to ensure that the controller is installed in an ambient temperature that does not exceed +45 degrees Celsius.

DKR02.1-W300B Technical Specifications

Rated Power Voltage:	3× AC 400 to 480
Weight:	104kg
System frequency:	50 to 60 Hz
Control Voltage power:	200Volts ampere
Continuous current of the drive at 4kHz swithcing freqency:	120A
Continuous current of the drive at 8kHz switching frequency:	95A
Peak current of the drive:	141A
Peak power of the drive:	55kW
Continuous regenerated power:	37kW
Peak regenerated power:	55kW

Frequently Asked Questions about DKR02.1-W300B

Q: What are the typical applications for the DKR02.1-W300B controller.

A: The DKR02.1-W300B controller is a very flexible device, and together with a compatible motor, it forms a rapid response automatization system that is suted for use in different industrial aplications such as printing machines, and Numeric Control machines.

Q: How many types of industrial motor can the DKR02.1-W300B controller be used with?

A: The DKR02.1-W300B controller is designed to be used with Rexroth Indramat motor series. It is specifically suited for the 2AD or ADF motor, the LSF or LAF linear motor and the 1MB frameless spindle motor.

Q: How is the DKR02.1-W300B configured?

A: The DKR02.1-W300B controller features special configuration modules that is inserted into the controller to configure it. These configuration modules include the software module, the command interface card, and the auxiliary plug in modules.

Q: Is the firmware delivered with the DKR02.1-W300B controller?

A: No. A configured controller must be ordered with the required firmware. The firmware is the operating software of the DKR02.1-W300B controller which is installed in the form of EPROM on the DSM software modules.

Q: Does the DKR02.1-W300B feature a brake resistor?

A: As a standard, the brake resistor is not integrated into the DKR02.1-W300B controller. However it is available as an option and operators can decide to purchase the controller with a brake resistor.
