Product Description
The Rexroth Indramat DKR02.1-W200N-BA03-01-FW is a digital drive controller. According to the type code for DKR controllers, the line is 2, the design is 1, the function numeric code is 03 and the version function numeric code is 01. Rexroth provides different software which are optimized for different applications. Therefore the firmware for the DKR02.1-W200N-BA03-01-FW needs to be ordered as a separate subposition. Command communication interface supported by the drive is analog. Nominal data for the controller are valid for 5 to 45 degrees Celsius ambient temperature and 0 to 100 meters altitude. The rated output for the DKR02.1-W200N-BA03-01-FW is 200 Amps. The drive input is compatible with three phase 400 to 480 Volts AC input at 50 to 60 Hertz. Integrated digital servo and resolver feedback is available on the drive.
The DKR02.1-W200N-BA03-01-FW comes with built in blower. The blower forces air across the controller heatsink to keep the operating temperature within recommended limits. Controller operation above 55 degrees Celsius is not recommended. Integrated bleeder is not available on the DKR02.1-W200N-BA03-01-FW controller. Load conditions need to be considered if the controller is operated under other than recommended ambient conditions. The controller power data are reduced by the load capacity. Overloading of the controller can also lead to damage. Controllers which are operated under conditions which are different from the recommended conditions can suffer damage leading to expiration of manufacturer guarantee. The DKR02.1-W200N-BA03-01-FW weighs approximately 104 kilograms. It is designed for vertical mounting with 80 millimeters of spading on the top and bottom side. All installation, commissioning and maintenance related activities should be performed by trained personnel. Failure to follow this recommendation can lead to improper installation and reduced operating life. This unit can be shipped globally with a one-year warranty period from Wake Industrial.
