Product Description
The Rexroth DKR02.1-W200N-BA01-01-FW is a modular drive controller rated for 200 Amps output. The controller is comprised of a basic unit with slots which can accommodate plug in modules. The firmware module for the controller installs in slot U5. Firmware for the controller needs to be ordered separately. The drive operating parameters are also stored on the firmware module. Command communication card for the controller, which is analog for the DKR02.1-W200N-BA01-01-FW, installs in slot U1. Slots U2 to U4 are available for optional plug-in cards. Optional module which are available for DKR controller include modules for CLC link interface, analog signal interface and modules for different measuring systems. A heatsink and blower and integrated in the housing of the DKR02.1-W200N-BA01-01-FW. Bleeder is not available on the drive controller.
Function numeric code for the DKR02.1-W200N-BA01-01-FW is 01. The version function numeric code is also 01. Integrated servo and resolver feedback is available on the drive controller. DKR 02 controllers are supplied for cooling with air outside the controller cabinet. The drive needs to be converted if a different cooing method is required. The DKR02.1-W200N-BA01-01-FW should be mounted in the vertical orientation. Input of the drive is rated for 400 to 480 Volts AC. The drive input can be directly connected to AC main supply. Total heat dissipated during operation by the drive is 1600 Watts. Approximate weight and dimensions of the DKR02.1-W200N-BA01-01-FW are 104 kilograms and 1000 x 440 x 290 millimeters. Permitted ambient temperature range with rated data is 13 to 113 degrees Fahrenheit. The maximum permitted ambient temperature with derating of nominal data to 80% is 131 degrees Fahrenheit. Maximum recommended setup height for the drive controller is 1000 meters. This unit can be shipped globally with a one-year warranty period from Wake Industrial.
