Product Description
The FWA-ECODR3-SMT-02V45-MS encoder firmware module with a version code of 2 for DKC drive controllers is manufactured by Bosch Rexroth. The ECODR3 series module has an analog interface for communication transfer. The drive controller is used for automation and machine tool applications. The firmware can be used with several drive controllers that operate with motors of different types from the same manufacturer. It is capable of displaying the diagnostic messages and parameter names in multiple languages. The Class A unit allows the selection and use of more than one operating mode and measuring system at a time. The module comes with a warranty for one year.
The firmware is primarily used in the product assembly and manufacturing sectors. The X8 interface of the drive controller can evaluate a measuring system comprising an EnDat interface as well as an incremental encoder with a square-wave or sine signal. The controller can be used only in the operating mode with an analog interface. It can be fitted with a motor holding brake through a potential-free contact. This brake helps to avoid unwanted axis movements in case the drive enabled signal gets turned OFF. This firmware version is an advancement of the first version of the same encoder firmware module.
The analog interface also helps in updating the firmware if needed. This interface encompasses parameters such as a 15-bit drive status word and a 15-bit master control word. The master control word parameter assists in storing the digital input signals. The drive status word stores various drive related status information such as drive error and current operation mode. The drive controller is available with three current rating options. The firmware unit weighs approximately 0.25kg. The FWA-ECODR3-SMT-02V45-MS module can be shipped to any address worldwide through our trustworthy and dedicated logistics and delivery team. This product is available from Wake Industrial with a one-year warranty period.
