DKC14.3-100-7-FW

Name: DKC14.3-100-7-FW
Brand: Bosch Rexroth Indramat
Price: 313 USD
Availability: InStock
Rating: 4.5 (14 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

MPN: R911294296

In-Stock, Ships Today

Current response time:

6 Minutes 40 Seconds

The DKC14.3-100-7-FW model of servo drive offered in a broad power spectrum by Bosch Rexroth marks its history by solving industrial automation problems. The DKC14.3-100-7-FW module offers communication through RS232 and analog interfaces.

Email

Phone

Part Number

+Add a message

Website

Preparing your secure checkout page...

Product Description

Bosch Rexroth Indramat has a remarkable history of designing, producing, and developing state-of-the-art drive control units specialized for industrial automation purpose. The DKC14.3-100-7-FW model of the intelligent drive controller comes without the firmware which needs to be separately ordered from Bosch Rexroth. The firmware should be installed prior to the operation to avoid any misbehave by the motor. This drive is rated for use in environment meeting degree 2 pollution. The device is designed to be cooled through natural convection for which it should be placed in free air-passage. This Indramat automation control unit is capable of operating at 100 A rated current. A rating plate and a nameplate is attached to the device which mentions drive controller series, version, types, and rated intermediate circuit voltage. The production week, change index, and barcode in printed on the rating plate attached to the drive unit. The drive controller DKC14.3-100-7-FW is equipped with RS232 interface and the analog interface. The RS-232 is a serial communication protocol that enables point-to-point data exchange between devices. The Analog interfaces transmit continuous signals to control parameters such as speed or torque.

The DKC14.3 drive controller comes with a 15-pole D-sub connector or motor feedback connection. The connection point X1 on the control board is designated for RS-232 serial bus interface. A fault clearance button and diagnostic indicator is available at the connection point H1 and S1 on the DKC14.3 control unit. The model DKC14.3-100-7-FW operates with nominal DC bus voltage of 700 V. the ambient operating temperature is above 0 and below +45 degree Celsius. The housing is enclosed to meet IP20 rating design requirements. It may only be used with accessories approved by Bosch. For sufficient heat dissipation, a minimum gap of 50mm should be allowed at the top and bottom of the drive controller unit (DKC14.3-100-7-FW). The DKC14.3 Indramat automation controller is suitable for applications that are to be used in at an elevation of 0 to 1000 MSL.

DKC14.3-100-7-FW Technical Specifications

Family:	DKC
DC bus voltage:	700 V
Over-voltage protection:	Yes
Site altitude:	1000 MSL
Optimal operating temperature:	0 to +40 degree Celsius
Firmware:	Not included
Pollution rating:	degree 2
Rated current:	100 A
Identification:	Plates
Connectivity:	15-pole D sub connector

Frequently Asked Questions about DKC14.3-100-7-FW

Q: Does the DKC14.3-100-7-FW model come with pre-installed firmware?

A: The DKC14.3-100-7-FW model comes without firmware. It needs to be separately ordered and installed from Bosch Rexroth prior to operation.

Q: How is the DKC14.3-100-7-FW drive controller cooled, and where should it be placed for optimal cooling?

A: The drive controller is cooled through natural convection and should be placed in a location with free air-passage for optimal cooling.

Q: What is the rated current for the DKC14.3-100-7-FW drive controller?

A: The DKC14.3-100-7-FW drive controller is capable of operating at a rated current of 100 A.

Q: What information is mentioned on the attached rating plate and nameplate of the DKC14.3-100-7-FW?

A: The attached rating plate and nameplate mention drive controller series, version, types, and rated intermediate circuit voltage. The production week, change index, and barcode are also printed on the rating plate.

Q: What connectivity options are available on the DKC14.3-100-7-FW, and where is the RS-232 serial bus interface located?

A: The DKC14.3-100-7-FW is equipped with a 15-pole D-sub connector for motor feedback connection. The RS-232 serial bus interface is designated at connection point X1 on the control board. A fault clearance button and diagnostic indicator are available at connection points H1 and S1 on the control unit.

Internal Product Review

‘‘The DKC14.3-100-7-FW offers a precise monitoring and speed control for a wide range of motors by Rexroth Indramat. The device has salient features as automatic parameters matching and adjustable error response. The device is available with IP20 degree of protection.’’
