DKC06.3-012-3-MGP-01VRS

Product Description

The Bosch Rexroth DKC06.3-012-3-MGP-01VRS is a EcoDrive Cs DKC10.3 series drive with ECM01.1-DN01 master communication card and DeviceNet support. The EcoDrive Cs is a series of advanced system-compatible AC servo drives that supports the 100 to 750 Watts power range. EcoDrive Cs series drives are equipped with SERCOS, Profibus, DeviceNet or CANopen communication modules. These drives are well suited to applications involving systems with multiple-axis devices and they can also be used as intelligent single axes on a standard filed bus. Motors with 100 Watts, 200 Watts, 400 Watts and 750 Watts power ratings can be adapted for used with EcoDrive Cs drives. Typical applications of EcoDrive Cs are machine tools, printing machines, mounting system and handling systems. The DKC06.3-012-3-MGP-01VRS can be used with 400 Watts rated motors.

The DKC06.3-012-3-MGP-01VRS drive has a current rating of 12 Amps and a DC bus rating of 300 Volts DC. The version of the firmware loaded onto the drive is 01. The firmware type is MGP (multi-interface general purpose). Approximate weight of the drive is 1.8 kilograms. The maximum allowed ambient temperature for drive operation is 55 degrees Celsius. However, the drive can be operated without output derating when the ambient temperature is between 0 and 40 degrees Celsius. The recommended range of temperatures for storage and transportation is -20 to 80 degrees Celsius. The maximum permitted installation altitude for operation with rated data is 1000 meters. The maximum permitted installation altitude for operation with de-rated data is 2000 meters. If the drive is installed at 2000 meters altitude then the maximum permitted ambient temperate is 40 degrees Celsius. The protection class of the DKC06.3-012-3-MGP-01VRS drive is IP20.
