DKC06.3-008-3-MGP-01VRS

Product Description

The Bosch Rexroth DKC06.3-008-3-MGP-01VRS is a EcoDrive Cs series drive with DeviceNet communication support. The rated current for the drive is 8 Amps. The DC bus voltage is 300 Volts DC. The drive firmware is MGP (multi interface general purpose). The version of the firmware is 01. Weight of the drive is 1.8 kilograms. The materials used for drive construction are free of silicone and asbestos. When used with single-phase 200 to 240 Volts AC input, the connected load for the drive is 0.7 kVA, the nominal input current is 1.3 Amps, the output current is 1.6 Amps, the maximum output current is 4.8 Amps and the base load at maximum current is 0.5 kVA. When used with three-phase 200 to 240 Volts AC input, the connected load for the drive is 0.7 kVA, the nominal input current is 1.3 Amps, the output current is 1.6 Amps, the maximum output current is 4.8 Amps and the base load at maximum current is 0.5 kVA.

The resistance of the soft-start resistor is 4.7 Ohms. The continuous power for the soft-start resistor is 17 Watts. The switching frequency can be set to 4 or 8 kilohertz on the DKC06.3-008-3-MGP-01VRS drive. The motor power dissipation is 52.2 Watts. The braking resistor peak power is 1.68 kilowatts. The continuous DC bus power is 253 Watts and the peak DC bus power is 864 Watts. The internal braking resistor on the DKC06.3-008-3-MGP-01VRS has a resistance of 100 Ohms, continuous power of 177 Watts and energy absorption of 400 Ws. The operation of the DKC06.3-008-3-MGP-01VRS at altitudes higher than 1000 meters causes derating. The maximum allowed installation altitude for the DKC06.3-008-3-MGP-01VRS is 2000 meters.
