Product Description
The DDS03.2-W030-BE23-01-FW is a DDS drive controller manufactured by the Rexroth Indramat Company. It features a maximum peak current of 30A and a continuous current of 12A. The environmental and ambient conditions under which it operates are a permissible temperature of 0 to 45 degrees, storage and transport temperature of -30 to 85 degrees, and a permissible relative humidity of 95% without condensation. It features a protection category of 1P 20 which requires mounting in a control cabinet that meets IP 10 demands. The maximum installation elevation with rated data is 1000 meters above sea level.
To connect the DDS03.2-W030-BE23-01-FW to the AC motors, a maximum cable length of 75 meters should be used. The cable should contain three lines for connection, a line for protective conductor connection, and a shielded pair of cables for monitoring the motor temperature. You should avoid instances of condensations as the humid air condenses on the drive components which leads to damage. The controller requires a large cabinet since one needs to use extensive heat conductance or heat exchanging units. This is because it uses heat technology that dissipates heat within the control cabinet. The high-powered controller should be mounted near the supply unit and vice versa.
The DDS03.2-W030-BE23-01-FW weighs approximately 5.5 kg. It comes with a SERCOS interface that allows the use of SERCOS controls to operate the drive via fiber optic cables. The software module comprises the firmware and drive parameters. The parameters can be transferred between units while the firmware undergoes continuous upgrades without affecting the functions of the drive. The firmware is ordered separately and it fixes the functional features. Get this Rexroth Indramat controller from Wake Industrial with a one-year warranty period.
