DDS03.1-W050-0

Name: DDS03.1-W050-0
Brand: Bosch Rexroth Indramat
Price: 150 USD
Availability: InStock
Rating: 4.6 (22 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

MPN: R911261190

In-Stock, Ships 3-5 Days

Current response time:

4 Minutes 12 Seconds

The DDS03.1-W050-0 is a modular drive controller manufactured by Bosch Rexroth Indramat. This controller is a very flexible device that can be used in conjunction with the MDD, MKD, LAR, LSF, 2AD, ADF, 1MB, and MBW motor designs. The controller is supplied by Rexroth Indramat as a fully configured unit featuring the configuration modules

Preparing your secure checkout page...

Description
Specs
FAQ

Product Description

The DDS03.1-W050-0 is an advanced industrial drive controller designed by Rexroth Indramat to carry out the accurate control of industrial motors. This controller is a modular device that is delivered as a fully configured device that is made-up of a basic unit, plugin modules, software modules, and the firmware. The controller is intended to be used with Indramat motor designs such as the MDD, MKD and LAR alternating current(AC) motors. The combination of this controller with any of these compatible motors from a rapid response drive system that is suited for use in machine tool, textile machines, printing and packaging machines, and well as robotics and handling machines. The controller is also very easy to handle, it is delivered with a documentation containing full instructions on the installation, commissioning, and general operation. The DDS03.1-W050-0 industrial drive controller meets the IP20 protection class, it also features an internal air blower that helps to dissipate the excess heat generated in the motor housing during operation. Also, unlike conventional industrial machines, this controller can operate at a top level for more than five years without the need for frequent repair operation. The supply unit used with this drive controller must always deliver a regulated 24 volt DC voltage, the controller should not be used with regulated supply unit such as the TVM supply unit. The DDS03.1-W050-0 industrial controller can be flexibly combined with several other drives to form a compact drive package that uses just one supply unit. The DDS03.1-W050-0 industrial controller should be stored in a dry, dust and shock free environment. Also the permissible ambient storage temperature should fall between -30 to about +85 degree Celsius.

DDS03.1-W050-0 Technical Specifications

Cooling:	Internal air blower
Display unit:	H1 display unit
Rated current:	50A
Permissible ambient temperature with rated data:	0 to 45 degrees celsius
Maximum permissible ambinet temperature with derated data:	55 degrees celsius
Storage and transport temperature:	-30 to +85 degrees ceslisus
Protection class:	IP20
Maximum permissible relative humidity:	95 percent
Weight:	7.5kg
Fault reset key:	Present

Frequently Asked Questions about DDS03.1-W050-0

Q: How does the DDS03.1-W050-0 controller communicate operational error?

A: The DDS03.1-W050-0 controller features an H1 display unit integrated into its housing unit. In the case of operational error, the controller displays an appropiate error code through the display unit.

Q: What is the fault reset key on the DDS03.1-W050-0 controller used for?

A: The fault reset key present on the DDS03.1-W050-0 is designed to restore the controller is an earlier state after operational error has been fixed. It gets the controller working again.

Q: What type of industrial motor is the DDS03.1-W050-0 controller suited for?

A: The DDS03.1-W050-0 controller is designed specifically for the MDD Rexroth motor series. The combination of the controller with this motor froms a rapid response automation system that can be used in various industrial environments.

Q: How many configuration modules are required by the DDS03.1-W050-0 controller?

A: Unlike earlier versions, the DDS03.1-W050-0 industrial controller only requires three configuration modules. The modules are the command communicaltion module, the auxiliary plug-in module and the software module.

Q: Can the DDS03.1-W050-0 controller be used in cold environments?

A: It is possible to use the DDS03.1-W050-0 controller in cold climates, however the ambinet temperature around the controller must not be allowed to drop below 0 degree celsius. Also, the rative humidity must not be higher then 95 percent.
