Product Description

DDS03.1-W050 is a Bosch Rexroth drive controller. It belongs to the DDS series of motor controllers. DDS controllers are compatible with several motor product lines manufactured by Bosch Rexroth. They work with linear and rotary industrial motors. DDS controllers require regulated 24 Volts DC input. Operators must take care to not use them with power supplies that deliver unregulated DC output. Bosch has made DDS controllers with an IP20 rated housing. Therefore, these controllers are made for indoor use. Outdoor use is possible when the controllers are mounted inside suitable cabinets. When installing DDS controllers, operators must provide suitable spacing to facilitate airflow which is necessary for proper cooling. Bosch recommends 40 millimeters on the front and 80 millimeter on the bottom and top of the mounted unit. Dimensions of the controller are 355 x 325 x 70 millimeters and its weight is 5.5 kilograms. Rated output of the controller is 50 Amps and it is designed for air cooling. The optimum ambient temperature is 0 to 45 degrees Celsius for operation and -30 to 85 degrees Celsius for storage. DDS controllers from Bosch have a modular design with slots that can accommodate option modules. DDS3.1 controllers have one designated slot for a software module, one designated slot for a communication module, and one slot for an optional module. DDS controllers support either resolver-based or digital servo feedback. This feature allows use of DDS controllers for applications requiring high precision and accuracy. A barcode sticker on the DDS03.1-W050 lists relevant information and specifications. Operators must check information listed on the sticker at the time of delivery. Any equipment damaged during transport must not be installed.
