DDS03.1-W030-RS18-02-FW

Product Description

The DDS03.1-W030-RS18-02-FW drive controller has a current rating of 30A and implements resolver feedback. This controller from Bosch Rexroth can act as a rapid-response drive when it is used with some of the AC motors from the same manufacturer. It must not be used with the TVM 1.2 supply unit because the DC voltage is not regulated. The product should be assembled, installed and operated only by qualified personnel. The device can be started only when the machine in which it is installed complies with EC 89/392/EWG directives. The electrical connecting points of the components of the unit must not be touched while it is turned on.

The drive controller has a discharge current rating of more than 3.5A. Incorrect usage of drive components can result in dangerous movements. The device must be de-energized with the help of the master switch during cleaning, repair and maintenance work. The unit has a function ID code of 18 and a version code of 02 for the function ID. The general safety regulations must be adhered to when handling the product. The firmware includes both the plug-in modules and software. The drive controller supports a one-year warranty from Wake Industrial.

The controller must be installed in a closed housing. The L+ and L- terminals of the product have a tightening torque of 3Nm. The supply lines and signal lines must be routed separately to avoid interference. The device is equipped with a display to highlight errors and warning messages. The unit must be connected to the AC motor using the manufacturer’s motor power cables. The connection to adjacent drive controllers is done through DC bus rails or stranded leads with a maximum length of 1m. The drive controller can be shipped to any address worldwide through our reliable logistics network.
