Product Description
The Bosch Rexroth DDS03.1-W030-DG01-00 is an advanced digital controller. It is deployed for control of motor parameters. The controller monitors and controls motor speed, position and torque. The DDS03.1-W030-DG01-00 supports digital servo feedback. This feature allows the controller to receive motor feedback. Motor feedback includes measurements of motor speed, position and torque. A sensor on the motor, known as an encoder, takes these measurements. The controller receives feedback and compares operating values with programmed values. A difference between the operating and programmed motor parameter values leads to change in the controller output. This known as closed-loop control and is required for high-precision industrial applications. The DDS controller series is compatible with MDD, MKD, LAR motors. The drive input voltage rating is 24 Volts DC. The DC input should be regulated.
As per the DDS series type code, the series of the controller is 3 and the version is 1. The function ID is 01 and the function ID version is 00. The controller firmware is ordered separately. A software module houses the controller firmware and drive parameters. To speed up drive commissioning, the contents of the software module can be copied to other software modules. If required, the software module can also be shifted to another controller. Each DDS controller includes a command communication module. The nominal current output of the DDS03.1-W030-DG01-00 is 30 Amps. The recommended temperature range for controller operation is 0 to 45 degrees Celsius. Site elevation should be between 0 and 1000 meters . The relative humidity should always be less than 95%. The controller dissipates heat inside the control cabinet. Protection category of the DDS03.1-W030-DG01-00 is IP20. Weight of the DDS03.1-W030-DG01-00 is approximately 5.5 kilograms.
