Product Description
The DDS02.2-W100-BE45-01-FW drive controller manufactured by Bosch Rexroth must be mounted inside a control cabinet. This controller has an IP 10 degree of protection as per DIN 40 050 standards. The product does not feature protection against penetration of water. The device is associated with a line code of 2. The unit supports installation only in vertical orientation. It is possible to connect multiple controllers with a single power supply. This product has an overall length of 355mm. The device installation should be done such that the signal and supply lines are routed away from each other to avoid interference. Adjacent units can be connected with the help of conductor rails.
The controller connection to the appropriate motor is performed using a power cable from the same manufacturer. This power cable has one line for its protective conductor connection, three lines for the motor power connection as well as a separately shielded cable pair for monitoring the motor temperature. The product uses its X1 connector for the control electronics. The device should neither be tipped nor dropped during transport. The unit is fitted with a rating plate on the front. Its X4 connector features the motor feedback. This DDS02.2-W100-BE45-01-FW controller features a one-year backup support period.
The product can be used with several AC motors like the MDD, 1MB, LAF series and more. This device must never be operated with an unregulated TVM 1.2 supply unit. This unit must be properly and correctly transported, stored, assembled and installed for safe and optimum operation. It is cooled by airflow inside the control cabinet in which it is installed. The functional features of this drive controller are determined by its firmware. The product must have a permanent earth wire connection as per the connection diagram after its installation. This drive controller can be sent worldwide to any international destination.
