Product Description
The Bosch DDS02.2-W100-BE12-01 is a digital drive controller. It is a modular device that is comprised of a basic unit with slots for mandatory and optional modules. The controller can be matched to customer requirements through the proper selection of firmware and optional hardware. The mandatory modules are a firmware module and a command communication module. The software module is where the drive parameters and firmware are stored. It is installed in slot U5 of the basic unit. The command communication module installed on the DDS02.2-W100-BE12-01 is SERCOS. This module installs in slot U1 of the basic unit. Slots U2 to U4 are available for any hardware modules that need to be installed later on. The DDS02.2-W100-BE12-01 controllers operates at 24 Volts DC input. This voltage must be supplied by a regulated DC power supply.
Rated output current of the DDS02.2-W100-BE12-01 controller is 100 Amps. This rated output is only valid for operating conditions that comply with those that are recommended by Bosch. The recommended ambient conditions include 0 to 45 degrees Celsius temperature and 0 to 1000 meters altitude. Operation of the controller outside these specified conditions leads to output current derating. The respective load factors multiply if both the temperature and altitude exceed specified limits simultaneously. The DDS02.2-W100-BE12-01 is designed for heat technology. The controller dissipates heat inside the cabinet where it is installed. As a result large cabinets must be used to ensure that the minimum inter-device spacing required for unobstructed airflow is maintained. The DDS02.2-W100-BE12-01 supports both digital servo feedback and resolver feedback. The controller and associated equipment should be handled by trained personnel. Relevant safety instructions should be following to prevent injury and equipment damage.
