Product Description
The DDS02.2-W015-BE11-01 drive controller does not have any associated firmware. The Bosch Rexroth drive controller permits two types of motor power cable connections. This connection can have either a terminal box or a connector style. The controller can be reset to the original state using the S2 button if a fault is encountered. The product has a three-phase current connection for the motor power cable. The device also comprises the ground connections to the power supply and motor at its top. The unit must make use of D subminiature plugin connectors or plugin clamps for its signal lines. Its components tend to get damaged due to electrostatic discharges.
The drive controller does not have any protection against water. The product along with the power supply must be installed in a closed housing. The device with excessive current levels and high output must be placed as close as possible to the power supply if multiple controllers utilize the same power supply. The L+, L- and PE connection terminals of the unit are connected using M6 screws that have a tightening torque of 3Nm. Its plug-in modules are supposed to be stored and transported in conductive packaging. The controller has a warranty period of one year.
This product depicts airflow inside the control cabinet as its cooling method. The device may require additional air conditioning to be implemented. The unit portrays a maximum permissible relative humidity of 95%. It comes with a 2 version code. The drive controller encompasses empty slots in its basic unit by default. These empty slots can support four application-specific plug-in modules and a software module. The product has individual type plates for the basic unit, hardware configuration and firmware. The functions of the device are determined by the firmware. This DDS02.2-W015-BE11-01 controller is delivered in custom military-grade packaging to avoid damage during transit.
