Product Description
The DDS02.2-W015-BA03-01-FW drive controller manufactured by Bosch Rexroth is used with the manufacturer’s motor. This drive controller is connected to the motor through a motor power cable and a motor feedback cable. The product must make use of only a 24VDC regulated power supply. The device is intended to be commissioned only after reading the associated documentation. The unit may cause personnel injury if it has exposed live parts with voltages of more than 50V. It is essential to check for the permanent connection of the earth wire as per the connection diagram after the installation process. The controller should encompass protection against indirect contact.
This product has a line code of 2. The device supports operation at an ambient temperature ranging between 0°C and 45°C with rated data. The unit must be mounted and installed inside a control cabinet. Its firmware should be procured as a separate subitem. The energy loss of the drive controller is based on the continuous current of the motor when it is in standstill mode. The product weighs approximately 7.5kg. The device comes with protection against penetration of external solid objects with diameters of more than 50mm. The DDS02.2-W015-BA03-01-FW controller can be dispatched to any place around the world with one-year backup support.
The drive controller mounting must be done such that there is a clearance distance of 80mm above and below it inside the control cabinet. It is possible to associate several controllers with a single power supply unit. The product comprises an H1 LED display and an S1 fault reset button on its front panel. The three-phase device must have a separate routing for its signal lines and supply lines. The connections of the unit have to be removed if an interference or high voltage test has to be executed. Its connection to an adjacent unit is established by means of DC bus rails.
