Product Description
The Bosch Rexroth DDS02.1-W200-DS37-01-FW is an air cooled drive controller. It is implemented with heat technology. This means that the controller dissipates heat inside the cabinet. Therefore large cabinets and air conditioning may be needed for maintenance of ambient temperature. The recommended operating temperature range for DDS controller is 0 to 45 degrees Celsius. The maximum permissible ambient temperature with derated data is 55 degrees Celsius. The recommended temperature for storage and transport is -30 to 85 degrees Celsius. The maximum installation elevation with rated data is 1000 meters. The maximum installation elevation with derated data is 5000 meters. The maximum permitted relative humidity is 95%. The protection category of the DDS02.1-W200-DS37-01-FW is IP20 as per EN 60529. The controller is not protected from water penetration and should be mounted inside a suitable cabinet.
The DDS02.1-W200-DS37-01-FW is rated for 200 Amps output. It can be used with a regulated power supply that provides 24 Volts DC. The DDS02.1-W200-DS37-01-FW supports integrated digital servo feedback. The command communication module on the drive is SERCOS. This module enables the operation of digital AC servo motors using control units equipped with a SERCOS interface. The media used for communication is fiber optics and the network nodes are deployed in a ring topology. SERCOS supports 2 Mbps and 4 Mbps data rates. DDS drives can also be ordered with SERCOS III modules that supports 100 Mbps full-duplex communication. Excellent performance data, flexible operating modes and application orientated functions of DDS drives make them ideal for CNC machine tool axes, electronic transmissions, grinding machines, robots, handling systems and assembly equipment. The controller firmware needs to be ordered as per application requirements.
