Product Description
The DDS02.1-W200-DS01-01 drive controller from Bosch Rexroth has a modular design. This digital drive controller belongs to the DDS product group of such offerings. The product has two DC bus terminals and three motor connection terminals on the front panel. The device is used to control and monitor the operation of an MDD series electric motor from the same manufacturer. The unit houses two outputs for monitoring analog signals. It can be configured with most 24V power supplies. The controller does not require any additional software other than the terminal emulation software.
This product is integrated with an oscilloscope functionality to store the signals in the drive. The device has a brushless design and is controlled by a microprocessor. The unit is cooled by heat dissipation with airflow inside the control cabinet. Its control, monitoring, diagnostics and parameterizing functions are carried out digitally. This controller uses a SERCOS interface for communicating its command signals. The product comprises an H1 status indicator. This indicator features a two-digit seven-segment display to indicate the operating status of the controller. This controller has a one-year warranty tag.
The three-phase device is a good choice for deployment in CNC machine tool axes. The unit comes with a configuration rating plate and a transparent protective cover. It can be fitted with a software module in its U5 slot. The drive controller supports a function code of 01 as determined by the manufacturer. The product portrays an earthing connection to the associated power supply module at its top. This device has an IP 10 protection rating as per DIN 40 050 specifications. The unit has to be commissioned before its start-up. It is to be ensured that the components of the controller correspond to the configuration rating plate data. This drive controller can be shipped anywhere in the world.
