Product Description
Bosch Rexroth is a leading manufacturer of modern automation applications and accessories. The accessories include brush-less servo motors, frequency converters, drive converters, and industrial professional power tools.
The DDS02.1-W150-DS24-03-FW model is a digital drive controller with outstanding motion control features. The DDS02.1 drive controller is a part of the DDS digital drive controller series by Rexroth Indramat. The model is a version '1' with air type cooling method. The drive controller is designed to be installed inside a cabinet with a forced ventilation system. For efficient ventilation, a sufficient gap should be provided around the device. The drive controller comes with current ratings of 150A and requires current from a 3-phase AC 380 - 460 V of power supply. Only verified power supplies should be used in conjunction with the control unit. The drive controller is engineered to provide high operational resolution and flexibility owing to its digital servo feedback system. The DDS02.1 drive controller uses an analog interface that makes communication easy and strong.
The model DDS02.1-W150-DS24-03-FW is well documented by Rexroth Indramat. The designations of the drive controller include DC link circuit connection at point X5 and control voltage bus connection at point X1. A connection point labeled as X3 is provided for Analog input/output devices. The motor feedback connection should be made at connection point X4. The drive controller allows an optional module for status display, alarm, and fault messages at the connection point H1. The product (DDS02.1-W150-DS24-03-FW) is shipped worldwide by Wake Industrial to its customers. Note that the drive controller has a separate connection point (X6) for the motor temperature monitoring module, motor holding brake, and 24V external power supply module.
