Product Description
The Bosch DDS02.1-W150-DS04-01 is an advanced drive controller. As per the product type code, the series is 2 and the version is 1. The function ID for the drive is 04 and the function ID version is 01. The drive controller can be used for applications that include robotics, grinding machines, assembly equipment, packaging machines and printing machines. The drive control, monitoring, parameterizing and diagnostics functions are digital and are performed by a dedicated signal processor. Each controller is comprised of a basic unit, drive firmware, plug in modules and a command communication module. Two slots on the basic unit are reserved for the software and command communication modules. Three slots can be used to accommodate optional plug in modules. The available range of plug in modules include gearwheel encoder interface, summing input interface, high-resolution position interface, incremental position interface, input/output interface, ARCNET coupler card and command card. Different firmware versions are also available.
The flexibility in the choice of firmware and plug in modules allows DDS controllers to be matched to various applications. Firmware for the DDS02.1-W150-DS04-01 as to be ordered separately from the hardware. Command communication module that is pre-installed on the drive supports SERCOS. This enables the use of the controller with digital AC motors that are equipped with a SERCOS interface. The drive supports digital servo feedback. Rated current output of the drive is 150 Amps. The output current falls below rated values if the ambient temperature or altitude exceed recommended limits. The DDS02.1-W150-DS04-01 cools via convection cooling. The heat is dissipated inside the control cabinet. The protection rating of the DDS02.1-W150-DS04-01 is IP20. The DDS02.1-W150-DS04-01 can be mounted inside a cabinet with the desired protection rating.
