Product Description
The Bosch DDS02.1-W150-DA06-00 is a DDS series drive controller. As per the product type code the series is 2 and the version is 1. The function ID of the controller is 06 and the function ID version of the device is 00. The controller is designed with heat technology and dissipates the heat generated during operation inside the cabinet. Therefore large cabinets and air conditioning may be required to ensure the ambient temperature is kept within allowed limits. DDS drives are designed for 0 to 45 degrees Celsius ambient temperature and 0 to 1000 meters altitude. If the ambient conditions are allowed to deviate from these specified limits then the output of the DDS02.1-W150-DA06-00 will derate and the drive could also malfunction. For facilitating the smooth flow of air, Bosch has recommended 80 millimeters clearance above and below the mounted controller and 22.5 millimeters behind the device. The rated output current of the drive is 150 Amps.
The drive supports digital servo feedback which allows it to receive feedback from the connected servo motor. The functionality of the DDS02.1-W150-DA06-00 is determined by the installed firmware. The drive firmware has to be ordered separately from the hardware. The firmware resides in the software module. The software module also contains the operating parameters that are configured by the user or operator. Each DDS controller has one command and communication module. The options for command communication modules include analog, SERCOS, single-axis positioning and Interbus. The DDS02.1-W150-DA06-00 features an analog command communication module. The DDS02.1-W150-DA06-00 is convection cooled. The IP20 rated rive housing installs in the vertical orientation. The DDS02.1-W150-DA06-00 and associated equipment should be installed and operated by trained personnel.
