Product Description
The DDS02.1-W050-DL08-01-FW drive controller manufactured by Bosch Rexroth has empty slots in the basic unit by default. The product portrays a line code of 1. This device has a single axis positioning module with the ability to program up to 3,000 program blocks that describe a motion sequence. The type designation of the unit helps to identify the components for each slot. It must be mounted after removing the faceplate. This faceplate must be refitted after the controller is mounted. The product encompasses a power section with a DC bus voltage of 300V +/-15%. The continuous current of the device must be set using the overload factor at the time of commissioning.
This drive controller has a weight of approximately 7.5kg. The current consumption of the drive is the sum of the current consumptions of the plug-in modules, basic unit and the motor feedback. The product can operate at a maximum temperature of 55°C with rated data. The device should never be operated near remote control, high frequency or radio equipment. The unit is intended to be handled and installed using appropriate lifting equipment and tools. It should be taken care that there is no pinching or crushing during the handling process.
The product encompasses both firmware and hardware in its configured state. The functions of this device are determined by the device. The unit comprises a status display to highlight the error and warning messages. It is connected to the adjacent unit using DC bus rails. The controller comprises a software module in its fifth slot. The motor feedback connection of this product is established through its X4 connector. The power cable for the line connection between the device and the AC motor must have a maximum length of 75m. This drive controller is available with a one-year warranty and supports international shipping to any country.
