Product Description
The Rexroth DDS02.1-W025-DL41-01-FW is a basic unit drive controller. It has the ability to solve multiple automation controlling desires if a specific option interface is installed onto the drive. It is used to control electrical motors and to operate them as required. Typical uses are metal fabrication machines, textile packaging, robotics and printing, paper processing machines, etc. The safety guidelines regarding installation, transportation, voltage, and movement should be considered appropriately in the operation of the drive controller. Personnel who work in the vicinity of machinery with the drive controller should be well trained and knowledgeable about their operation. High-frequency, remote control, and radio equipment near the equipment electronics and supply leads should be avoided. If such a unit cannot be avoided, the system and the plant should be checked for possible malfunctions at all positions of regular use before the first start-up.
The rated current for the DDS02.1-W025-DL41-01-FW is 25 Amperes, and it is available with
digital servo motor feedback. It features a cold technology method using airflow from outside the control cabinet. Firmware for the drive controller is ordered as a separate item meaning it is possible to reorder the same firmware version. The software module needed depends on the selected hardware configuration and the functions of the drive. A DC bus voltage of 300 Volts (+/- 15%) is required to power the drive controller. The maximum peak current/ continuous current and peak current/ maximum continuous current is 25A/25A. The current consumption of the drive controller is DC +/-15V estimated at 200 mA, for DC +24V 1100 mA. The permissible operating temperature is between 0 to 45 degrees Celsius. Allowable storage and transportation temperature is from -30 to 85 degrees Celsius.
