Product Description
Bosch Rexroth provides sustainable and cost-effective solutions to industrial automation problems. The solution comes with products like drive controllers, synchronous motors, and brake choppers.
The DDS02.1-A050-DG01-00 model is a drive controller manufactured by Rexroth Indramat to be used together with the respective AC electrical motors and main drives. The model represents the family of a digital intelligent drive system and it provides high performance when used according to the prescribed mounting and operating conditions. The DDS02.1 drive controller takes 15 – 24 VDC input power through its L- and L+ terminals and it delivers the three-phase output current to the attached motor via A1, A2, and A3 terminals. The faults and errors of the model can be displayed by the Status LED and a reset switch is also placed in this unit. The model performs effective communication via a command interface card installed in the U1 slot and digital servo feedback is installed in this unit to control the speed and motion of the attached AC synchronous or linear motor. The DDS02.1 drive controller operates at the rated current of 50 A, and the overall power loss of the unit is 200 mA for a 15VDC unit and 1100 mA for a 24 VDC unit.
The model DDS02.1-A050-DG01-00 is widely used in various motion control systems such as machine tools, mounting systems, textile machines, and handling systems. The protection category of the DDS02.1 unit is IP20 and it should be installed under the temperature range of 0 to +45 degree Celsius. The firmware is not supplied along with this unit and it must be ordered separately according to the required configurations. During installation, provide sufficient room at the top and bottom of the unit for airflow in the control cabinet. You can get this product (DDS02.1-A050-DG01-00) along with a one-year replacement warranty from Wake Industrial.
