DDC01.1-K050A-DL20-01-FW

Product Description

The DDC01.1-K050A-DL20-01-FWdigital AC servo drive from Bosch Rexroth is a three-phase current drive. The operation of the brushless drive is controlled by a signal microprocessor based on the measurement of the rotor position. This drive can function as a digital single-axis positioning controller when it is fitted with a single-axis positioning module from the same manufacturer. The product belongs to the DDC product group of digital drives. The device operates in conjunction with an MDD series AC servomotor. The connections to the motor are achieved through a motor power cable and a motor feedback cable. Its parameters are loaded on a software module.

The servo drive has a series code of 1 and a version code of 1. The product comes with an IP 65 protection rating. It can be mounted directly on to the forward feed unit. The device is equipped with a bleeder resistor. This resistor tends to get hot when the drive is in use. The unit has a length of 517.5mm without the blower. Its front features a dedicated slot for inserting the software module. The H1 status display highlights the error and warning signals. The product must always be grounded according to the manufacturer’s guidelines to avoid coupling interference.

The DC bus dynamic brake gets activated when there is a problem with the servo drive. The components of the device should be compatible with their mains voltages. The parameters of the drive must be programmed before it is started. The drive may have dangerous movements if the connections are done incorrectly. This might cause property damage or bodily injury. The connected drive controller can be used to set the drive response in case of an error. The unit comes to a standstill based on the error reaction. The DDC01.1-K050A-DL20-01-FW features a one-year Wake Industrial warranty and can be sent worldwide.
