CML45.1-3P-500-NA-NNNN-NW

Name: CML45.1-3P-500-NA-NNNN-NW
Brand: Bosch Rexroth Indramat
Price: 491 USD
Availability: InStock
Rating: 4.7 (38 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

MPN: R911170828

Unused Original Box Pricing Available!

In-Stock, Ships 3-5 Days

Current response time:

4 Minutes 19 Seconds

CML Control Drive is manufactured by Rexroth, Indramat, Bosch. This drive has 8 input terminals and 8 output terminals. The voltage of this drive is 24V dc and the network type is Ethernet. This drive's memory is min 256 MB.

Preparing your secure checkout page...

Description
Revisions
Specs
FAQ

Product Description

Bosch Rexroth has always been a market leader in the industry of motion control and industrial automation. Their latest version of the popular IndraControl series provides various ranges of powerful drive controllers which can effectively manage the functions of many integrated machines within a factory. The IndraControl L45 range provides a cost-effective automation solution to factory operators, with considerable benefits such as an easy-to-understand visualization and integrated control and diagnostics.

Bosch Rexroth’s CML45.1-3P-500-NA-NNNN-NW is part of the IndraControl L45 series and is a main unit product. The CML45.1-3P-500-NA-NNNN-NW has an inline housing design and a specific comexpress line. The design for the CML45.1-3P-500-NA-NNNN-NW is characterized as LX800, 500MHz and the controller has two communication interfaces. The first one is a SERCOS III interface and the second is a PROFIBUS interface. The system configuration for the CML45.1-3P-500-NA-NNNN-NW controller is that it has a DRAM of 256 MB and does not feature additional NvRAM or SRAM.

The residual ripple for the CML45.1-3P-500-NA-NNNN-NW is +/- 5% and the entire unit weights approximately 1.5 kgs, making it a compact unit to be employed anywhere in the factory. Since the CML45.1-3P-500-NA-NNNN-NW unit has a robust exterior, the permissible temperature for operation ranges from 5 °C to 55 °C. Additionally, the permissible relative humidity for operation ranges from 5% to 95%, and the entire CML45.1-3P-500-NA-NNNN-NW unit has an IP20 protection category. In order to aid effective operation, the CML45.1-3P-500-NA-NNNN-NW features a single-line display for control purposes with four operating keys, an LED and a reset button. The LC display comprises of 8 digits and a 5 x 10 dot matrix. Bosch Rexroth’s CML45.1-3P-500-NA-NNNN-NW is one of the simpler controllers from the IndraControl series and does not feature a fan or an integrated firmware. The material number for this unit is R911170828. This control unit can be shipped globally with a one-year warranty period from Wake Industrial.

CML45.1-3P-500-NA-NNNN-NW Technical Specifications

Memory DRAM:	min 256 MB
Standard communication Interfaces:	1×Ethernet TCP/IP, 1× Single Pole ready contact.
CPU:	×86 compatible, 500MHz
RAM:	512MB
Removable storage medium:	CF card/1GB
Real time clock :	integrated
Display:	1 line, 4 operator keys.
Protection Category:	IP20
Nominal power supply voltage:	24V
Input/Output Modules:	Inline

Frequently Asked Questions about CML45.1-3P-500-NA-NNNN-NW

Q: What type of industrial application is the CML45.1-3P-500-NA-NNNN-NW designed for?

A: The CML45.1-3P-500-NA-NNNN-NW is an high performance compact controller designed for demanding PLC motion applications and CNC applications. It is easily configured and maintains a high operational accuracy in these applications. AB53

Q: How is the temparature of the CML45.1-3P-500-NA-NNNN-NW controlled?

A: The CML45.1-3P-500-NA-NNNN-NW does not feature an internal air blower, however its operational temperature can be effectively regulated by surface cooling. An external air blower can also be installed into the control cabinet to aid temperature regulated.

Q: Is it testing of the CML45.1-3P-500-NA-NNNN-NW necessary before operation?

A: The CML45.1-3P-500-NA-NNNN-NW is already tested and certifed by well trained engineers before delivery. Customers can however carry out personal testing according to the instructions in the documentation of the drive.

Q: Is the CML45.1-3P-500-NA-NNNN-NW covered by a warranty?

A: All CML45.1-3P-500-NA-NNNN-NW purchased from our store is covered by a 12 month warranty. Customers will receive a new controller if an unexpected damage occurs while the device is being used according to instructions in the documentation.

Q: What is the proper conditions for the operation of the CML45.1-3P-500-NA-NNNN-NW?

A: The CML45.1-3P-500-NA-NNNN-NW controler should be operated in a dry environment that is free from dust and other solid particles. The ambient temperature at which the controller is operated should not exceed 400C.
