BTA16 Series

The BTA16 is a machine control board designed and manufactured by Rexroth Indramat. These boards are designed for high performance of AC control applications where the immunity to high noise and high di/dt are required. The maximum operational ambient temperature of the control board is between +5oC to +45oC, the operational air pressure is 860 to 1060 hPa, 1500 m, and the maximum heat dissipation is 10 W. The INTERBUS module is a digital device with inputs and outputs and contains the entire active electronics. The front panel is made of varnished aluminum with a polyester foil that is chemically resistant with a protection rating of IP65.
