KL3204-0018

Name: KL3204-0018
Brand: Beckhoff
Price: 194 USD
Availability: InStock
Rating: 4.6 (33 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

In-Stock, Ships Fast

Current response time:

3 Minutes 36 Seconds

The KL3204-0018 is a compact and lightweight analog input module, weighing approximately 70g and offering four inputs with a 0.1°C resolution per digit. Manufactured by Beckhoff within their KL Analog Input Series, it supports sensor types such as Pt100 and Ni1000. It conforms to EN 61000-6-2/EN 61000-6-4 EMC standards.

Email

Phone

Part Number

+Add a message

Website

Preparing your secure checkout page...

Product Description

The KL3204-0018 is a bus terminal developed by Beckhoff, a company known for producing innovative solutions for automation technology. The terminal is made to measure temperature using different kinds of sensors to give computer systems accurate and reliable data processing. The terminal comes with many useful features that make sure temperature readings and controls work perfectly in industrial automation settings.

The KL3204-0018 bus terminal works with different kinds of sensors, such as Pt200, Pt100, Pt1000, Pt500, Ni1000, Ni120, and Ni100. The bus terminal also works with resistance measuring tools, such as potentiometers, that range from 10 Ω to 1.2/5 kΩ. Ni sensors can measure between -60°C and +250°C and Pt sensors can measure between -200°C and +850°C. There are two wires used to connect the product, and the exchange time is usually 250 ms. The terminal gives a very accurate reading with a range of less than ±1°C and a precision of 0.1°C per digit. The KL3204-0018 usually has a measuring current of 0.5 mA and can separate the K-bus voltage from the signal voltage with 500 V of electrical separation and around 60 mA from the K-bus.

The KL3204-0018 bus terminal is special because it can find open circuits and doesn't need to be coded with an address because it can be set up by the user or the Bus Coupler. Weighing about 70 grams, it can work in temperatures ranging from -25°C to 60°C. It can be stored from -40°C to 85°C. It meets many standards, such as EN 60068-2-6 and EN 61000-6-2, so it works well in a lot of different settings and CE, UL, ATEX, IECEx, and DNV GL have cleared it. We offer reliable customer service and ship our products all over the world.

KL3204-0018 Technical Specifications

Number Of Inputs:	4
Current Consumption K-bus:	typ. 60 mA
Bit Width In The Process Image:	input: 4 x 16 bit data (4 x 8 bit control/status optional)
Special Features:	open-circuit recognition
Weight:	approx. 70 g
Operating/storage Temperature:	-25…+60°C/-40…+85°C
Vibration/shock Resistance:	conforms to EN 60068-2-6/EN 60068-2-27
Power Supply:	via the K-bus
Sensor Types:	Pt100, Pt200, Pt500, Pt1000, Ni100, Ni120, Ni1000
Measuring Range:	-200…+850°C (Pt sensors); -60…+250°C (Ni sensors)
Connection Method:	2-wire
Conversion Time:	~ 250 ms
Measuring Current:	typ. 0.5 mA
Resolution:	0.1°C per digit
Measurement Error/uncertainty:	< ±1°C

Frequently Asked Questions about KL3204-0018

Q: How does the KL3204-0018 ensure accurate temperature measurements?

A: The KL3204-0018 provides high accuracy with a resolution of 0.1°C per digit. This minimizes measurement error to less than ±1°C.

Q: How does the KL3204-0018 manage electrical isolation?

A: The KL3204-0018 features 500 V electrical isolation between the K-bus and signal voltage. This ensures safe operation and signal integrity.

Q: Why does the KL3204-0018 have open-circuit recognition?

A: The KL3204-0018 includes open-circuit recognition to detect faulty sensor connections. This feature improves system reliability by identifying connection issues.

Q: Do KL3204-0018 sensors cover a wide temperature range?

A: The KL3204-0018 measures from -200°C to +850°C for Pt sensors. Ni sensors cover a range of -60°C to +250°C.

Q: Does the KL3204-0018 require configuration for operation?

A: The KL3204-0018 does not require a manual address setting. It is configured via the Bus Coupler or controller for simplified integration.

Internal Product Review

‘‘The KL3204-0018 by Beckhoff is a highly reliable bus terminal for temperature measurement. It supports a wide sensor range, including Pt and Ni sensors, ensuring versatile application. The product offers 500 V electrical isolation and open-circuit recognition, making it both safe and efficient in automation systems.’’
