CX8050

Name: CX8050
Brand: Beckhoff
Price: 408 USD
Availability: InStock
Rating: 4.5 (13 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

In-Stock, Ships 3-5 Days

Call for Expedited Shipping and Product Condition Options

The CX8050 Embedded CPU by Beckhoff features a 400 MHz Arm9 processor, 512 MB microSD flash memory, and supports IEC 61131-3 programming. Its 1-second UPS and passive cooling ensure efficient, reliable operation.

Preparing your secure checkout page...

Description
Revisions
Specs
FAQ

Product Description

The CX8050 Embedded CPU is a compact and high-performance controller designed for industrial automation. Developed by Beckhoff, it features an Arm9 processor running at 400 MHz that provides efficient control capabilities. The device includes 512 MB of microSD flash memory, expandable for larger projects, and 64 MB of DDR2 RAM for effective data handling. Its key features include support for web-based management, online code changes, and web visualization, making it a versatile solution for automation tasks.

The CX8050 embedded CPU offers several technical features that enhance its functionality. It supports IEC 61131-3 programming languages that allow engineers to easily program and manage control software. The system provides one RJ45 10/100 Mbit/s Ethernet interface for communication. It includes a USB device interface behind the front flap, and a D-sub connector adhering to CANopen specifications. The CAN bus interface is galvanically decoupled to ensure secure and reliable data transmission. Passive cooling is used for efficient heat dissipation without moving parts. The CX8050 also includes an integrated 1-second UPS with 1 MB storage on the microSD card that ensures minimal data loss during short power interruptions. The device's internal battery-backed clock ensures accurate timekeeping and is easily replaceable via the front flap.

The CX8050 CPU operates on the Windows Embedded CE 6 operating system and is compatible with Beckhoff's TwinCAT 2 PLC software for control tasks. The system automatically recognizes I/O connections via E-bus or K-bus which are powered by a 24 V DC power supply. The maximum power consumption of the device is 3 W while the E-bus/K-bus current supply provides up to 2 A with a maximum power consumption of 10 W. Diagnostic LEDs for TC and bus status allow real-time monitoring of the system.

CX8050 Technical Specifications

Processor Speed:	400 MHz
Power Supply:	24 V DC
Flash Memory:	512 MB microSD
RAM:	64 MB DDR2
Ethernet Interface:	1 x RJ45 10/100 Mbit/s
USB Interface:	USB device (behind front flap)
CANopen Connector:	D-sub connector
Galvanic Isolation:	Yes
Operating System:	Windows Embedded CE 6
Software Compatibility:	TwinCAT 2 PLC

Frequently Asked Questions about CX8050

Q: How does passive cooling benefit the CX8050 CPU?

A: The passive cooling in the CX8050 Embedded CPU (CX8050) ensures reliable operation by dissipating heat without moving parts. This increases durability and reduces maintenance needs.

Q: Why is the CANopen interface decoupled in the CX8050?

A: The CX8050 Embedded CPU features galvanic decoupling for its CANopen interface, ensuring safe and secure data transmission. It minimizes risks of electrical interference or faults.

Q: How does the integrated UPS in CX8050 reduce data loss?

A: The 1-second UPS in the CX8050 Embedded CPU (CX8050) provides 1 MB of backup storage. This feature minimizes data loss during power interruptions.

Q: What role does the internal clock play in CX8050?

A: The CX8050 Embedded CPU has a battery-backed clock to maintain accurate timekeeping. It enhances system scheduling and logging accuracy.

Q: How does E-bus/K-bus recognition work in CX8050?

A: The CX8050 CPU automatically detects I/O connections via E-bus/K-bus, simplifying system configuration. This feature ensures seamless integration and setup.

Internal Product Review

‘‘Beckhoff's CX8050 Embedded CPU is a top choice for industrial automation with its 400 MHz Arm9 processor, 512 MB microSD flash memory, and galvanically decoupled CAN bus interface. Its 1-second UPS ensures minimal data loss, while passive cooling guarantees reliability in demanding environments.’’
