The B&R 3AI350.60-1 features 8 differential voltage input channels. The nominal input signal range of -10 V to +10 V can be extended to -20 V to +20 V, accommodating a broad spectrum of signals. Equipped with digital converters offering a 12-bit resolution, the module ensures accurate analog-to-digital conversion, crucial for capturing fine data details.

Email

Phone

Part Number

+Add a message

Website

Preparing your secure checkout page...

Product Description

The 3AI350. 60-1 is a sinister High-precision analog input module equipment important mechanism of B & R system 2005 Automation solution. This module samples the analog signal and converts it into digital data which is important in various industrial processes and data acquisition.

It has 8 differential voltage input channels, which enables the measurement of voltage differences. The nominal input signal range is -10 V to + 10 V but can be adjusted to -20 V to + 20 V to adapt to a variety of signals. The module is equipped with digital converters with a 12-bit resolution, providing accurate A/D conversion necessary for processing fine data detail. It holds a conversion time of less than 1 ms in the normal mode and less than 1. 5 ms when averaging is active, which is critical for real-time data analysis. With a basic accuracy of ~0. 1% at 25 degrees C and a repeat precision of ~0.025%, the 3AI350.60-1 is accurate for use in situations, which require a high degree of accuracy in data. The differential input resistance is 2 M, which means that it does not load the input signals and maintains accurate measurements. The signal noise is minimized by implementing a first-order low-pass filter with a cut-off of 450 Hz. The power dissipation of the module is at most 1 W when supplied with 5 V and 3. 5 W with 24 V, bringing the total to 4. 5 W, suitable for application in larger systems concerning energy consumption.

Temperature drift specifications include an offset drift of ~0. 0037 per degree Celsius and a gain drift of ~0. 00 75% per degree Celsius to ensure stability over a range of operating temperatures. Further, the coupling between channels is -66 dB which reduces cross-talk and provides accurate measurement for all input channels. The 3AI350. 60-1 module is a highly reliable part designed for industrial applications that need precise and fast analog-to-digital conversion, thus serving as a key component in contemporary automation systems. The product is available at Wake Industrial with a one-year warranty period.

3AI350.60-1 Technical Specifications

Module Type:	Analog Input Module
Power Dissipation:	1 W with a 5 V supply and 3.5 W with a 24 V supply
Series:	B&R System 2005
Analog Input Channels:	8 Voltage Input channels
Nominal Input Signal Range:	-10 V to +10 V
Maximum Input Signal Range:	-20 V to +20 V
Resolution:	12-bit resolution
Conversion Speed:	1 ms in Normal mode and less than 1.5 ms with Averaging active
Accuracy and Precision:	Accuracy of ~0.1% at 25 degrees C and a Repeat Precision of ~0.025%
Input Resistance:	2 M?

Frequently Asked Questions about 3AI350.60-1

Q: What is the input signal range of the 3AI350.60-1?

A: It handles a nominal range of -10 V to +10 V, expandable to -20 V to +20 V.

Q: What is the conversion time of the 3AI350.60-1?

A: The conversion time is less than 1 ms in normal mode and less than 1.5 ms with averaging active.

Q: How accurate is the 3AI350.60-1 module?

A: It offers a basic accuracy of ~0.1% at 25 degrees C with a repeat precision of ~0.025%.

Q: What are the power requirements of the 3AI350.60-1?

A: The module consumes 1 W with a 5 V supply and 3.5 W with a 24 V supply, totaling 4.5 W.

Q: Does the 3AI350.60-1 include any features to enhance signal integrity?

A: Yes, it includes a first-order low pass filter with a cutoff of 450 Hz to minimize noise and ensure clear signal processing.

Internal Product Review

‘‘The B&R 3AI350.60-1 stands out as a high-precision analog input module, crucial for industries that depend on accurate and timely data acquisition. Its robust design, coupled with advanced filtering and minimal power consumption, ensures reliable performance under varying operational conditions. Ideal for sectors requiring detailed data analysis, this module enhances the efficiency and precision of industrial automation systems.’’
