8V1090.00-1

Name: 8V1090.00-1
Brand: B & R Automation
Price: 368 USD
Availability: InStock
Rating: 4.8 (16 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

In-Stock, Ships 1-2 Days

Call for Expedited Shipping and Product Condition Options

The 8V1090.00-1 is manufactured by B&R Automation as part of their ACOPOS Intelligent Servo Drives. The 8V1090.00-1 has a 400 VAC - 480 VAC main input voltage and a frequency of 50/60 Hz. This servo drive features a Max. 5 kVA installed load and a 24 VDC nominal input voltage.

Request a Quote Request Repair

Preparing your secure checkout page...

Description
Revisions
Specs
FAQ

Product Description

The B&R 8V1090.00-1 is an industrial drive. It belongs to the ACOPOS product line. The output power rating of the drive is 4 kilowatts. ACOPOS drives are widely deployed in the packaging industry, paper and printing, wood industry, textile and metalworking industry. ACOPOS drives are thoroughly tested during development. During testing the drives are subjected to loads that greatly exceed loads experienced during everyday operation. ACOPOS drives are modular products that support a wide range of plug in modules. Plug in modules are available for network communication, connection to visualization devices, encoders, actuators and sensors. CPU modules for drive and controller integration are also available. Operators can configure the drive from B&R Automation Studio software. Tasks such as transport, installation, commissioning and servicing of the drives are only permitted to be carried out by qualified personnel.

The 8V1090.00-1 drive has four slots for plug in modules. Input voltage range for the drive is 400 to 480 Volts AC (three-phase). The specified ambient temperature range is 0 to 40 degrees Celsius. The nominal operating altitude is 0 to 500 meters. Drive use outside these limit leads to output derating. Mechanical specifications for the 8V1090.00-1 include 4.4 kilograms weight and drive dimensions of 375 x 235.5 x 70.5 millimeters. The connections for the motor temperature sensors and the motor holding brake are isolated circuits. Therefore, these connections are only allowed to be connected to devices or components with at least safe isolation in accordance with IEC 60364-4-41. Before turning on the servo drive, make sure that the housing is properly connected to ground. Sufficient space of at least 80 mm must be left above and below the ACOPOS servo drives in order to ensure proper air circulation.

8V1090.00-1 Technical Specifications

Frequency:	50/60 Hz
Weight:	4.4Kg
Mains Input Voltage:	3×400 to 480 VAC
Starting Current:	20A
Switch-on Interval:	>1 min
Continuous Power Output :	200W
Peak Power Output :	7Kw
Integrated Brake Chopper:	Present
Power connections:	Plug Connection
Maximum Switching Frequency:	20KHz

Frequently Asked Questions about 8V1090.00-1

Q: What type of industrial motor can I use the 8V1090.00-1 for?

A: The 8V1090.00-1 is a flexible servo drive that is suitable for both synchronous and asynchronous servo motors. It also has a built-in line filter which meets the limit value for CISPR11.

Q: How can industrial operators detect operational errors in the 8V1090.00-1?

A: The 8V1090.00-1 features three light emitting diodes which can be used for diagnosis. During operational error, the light emitting diodes flash red light to alert industrial operators.

Q: Can I use third party cables with the 8V1090.00-1?

A: Yes, however the cables must have the same wave parameters as defined in the documentation supplied with the servo drive. If deviations exist, additional measures are necessary to ensure that EMC guidelines are met.

Q: What is the recommended environmental conditions for the installation of the 8V1090.00-1?

A: The 8V1090.00-1 should only be installed in an environment that correspond to pollution degree II. Also the ambient temperature around the drive should not exceed 40 0C

Q: Can the 8V1090.00-1 be directly installed in the industrial environment?

A: The housing of the 8V1090.00-1 only provides protection according to the IP20 protection class. To guarantee effective protection, the drive should be installed in a control cabinet that can meet at least the IP54 protection class.
