8LSA35.DB030S300-3

Name: 8LSA35.DB030S300-3
Brand: B & R Automation
Price: 414 USD
Availability: InStock
Rating: 4.6 (19 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

In-Stock, Ships 3-5 Days

Current response time:

5 Minutes 13 Seconds

The 8LSA35.DB030S300-3 is a synchronous motor with a rated speed of 3000 RPM and a feedback mechanism using a resolver. Manufactured by B & R Automation under the 8LS Series, it operates at 400 V and weighs 3.9 kg. This motor has a rated torque of 1.95 Nm, natural cooling, and an IP65 protection class.

Email

Phone

Part Number

+Add a message

Website

Preparing your secure checkout page...

Product Description

The 8LSA35.DB030S300-3 is a high-performance synchronous servo motor designed for precise motion control applications. This motor is suitable for various industrial uses, providing reliable operation in demanding environments.

This synchronous motor 8LSA35.DB030S300-3 operates at a rated speed of 3000 RPM and delivers a rated torque of 1.95 Nm. The motor has a maximum torque capability of 5.6 Nm. It runs on a 400 V power source and delivers a rated output of 0.61 kW. The motor utilizes a natural cooling system, allowing it to maintain optimal performance without requiring any extra cooling devices. With an IP65 protection rating, the motor is effectively shielded from both dust and water intrusion. With a system inertia of 0.049 kgm^2, the motor provides precise control in dynamic applications. The 8LSA series motor is coated with polyester powder with a color similar to the RAL 9005 flat. This provides durability and resistance to environmental factors. The motor should only be installed and operated by a qualified technician with specialized training to ensure optimal performance and safety. Proper installation and operation are critical to achieving the maximum efficiency and longevity of the motor.

The 8LSA35.DB030S300-3 motor includes a resolver with 2.1 multi-turn feedback which offers precise position and speed feedback. With a weight of 3.9 kg, the motor is relatively lightweight. The motor can handle relative humidity levels from 5 % to 95 % that ensures reliable performance across different operating conditions. Wake Industrial distributes this product globally and offers a replacement warranty. In the event of a defect, malfunction, or any other issue with the product, the warranty claim process is straightforward and user-friendly. Customers can easily initiate a claim by contacting our customer support team.

8LSA35.DB030S300-3 Technical Specifications

Type:	Synchronous Motor
Feedback:	Resolver (2.1 multi-turn)
Protection Class:	IP65
Cooling Type:	Natural Cooling
Environmental Temperature:	0 to 40 degrees C
Weight:	3.9 kg
Voltage:	400 V
Rated Speed:	3000 RPM
Rated Torque:	1.95 Nm
Maximum Torque:	5.6 Nm
Rated Power:	0.61 kW
Maximum Current:	14.3 A
Rated Current:	2.2 A
System Inertia:	0.049 kgm^2

Frequently Asked Questions about 8LSA35.DB030S300-3

Q: How does the 8LSA35.DB030S300-3 motor ensure reliable performance in demanding environments?

A: The motor features an IP65 protection class that guards against dust and water ingress. Its natural cooling system maintains optimal performance without additional cooling mechanisms.

Q: What are the electrical specifications for the 8LSA35.DB030S300-3 motor?

A: The 8LSA35.DB030S300-3 motor operates on a 400 V supply with a rated power output of 0.61 kW. It is designed for precise motion control applications.

Q: Can the 8LSA35.DB030S300-3 motor operate under varying environmental conditions?

A: Yes, it is designed for continuous operation in ambient temperatures from 5 degrees C to 40 degrees C. It also handles relative humidity levels from 5% to 95% effectively.

Q: What feedback system does the 8LSA35.DB030S300-3 motor use?

A: The 8LSA35.DB030S300-3 motor includes a resolver with 2.1 multi-turn feedback. This system offers precise position and speed feedback for dynamic control applications.

Q: What is the rated speed and torque of the 8LSA35.DB030S300-3 motor?

A: The 8LSA35.DB030S300-3 motor operates at a rated speed of 3000 RPM with a rated torque of 1.95 Nm. It also has a maximum torque capability of 5.6 Nm.

Internal Product Review

‘‘The synchronous servo motor 8LSA35.DB030S300-3 offers a robust IP65 protection class, 3000 RPM speed, and 1.95 Nm rated torque. The model has a 0.61 kW power output and integrated resolver feedback. This motor provides exceptional precision and reliability. This servo motor is the best choice for dynamic applications.’’
