8BVI0220HCD8.000-1

Name: 8BVI0220HCD8.000-1
Brand: B & R Automation
Price: 347 USD
Availability: InStock
Rating: 4.3 (35 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

In-Stock, Ships 1-2 Days

Current response time:

6 Minutes 43 Seconds

The 8BVI0220HCD8.000-1 inverter module is an ACOPOSmulti type with a current rating of 22 amps, high voltage rating, and can control 2 axes. Part of the 8BVI Series manufactured by B & R Automation, it offers cold plate or feed-through mounting options and has a repair service price of $1,065.00 USD.

Preparing your secure checkout page...

Description
Specs
FAQ

Product Description

The B& R Automation 8BVI0220HCD0.000-1 is an advanced ACOPOSmulti inverter module designed for seamless operation in automation applications. It integrates two fully independent power inverters within a single inverter module, optimized for two-axis applications. The module supports integrated uncontrolled standstill and safe stop functionality, ensuring safety during operations. It features an integrated connection for a motor holding brake and temperature sensor, enhancing control and reliability. The module is equipped with two slots available for ACOPOSmulti plug-in modules, ensuring flexibility in customization and expansion of the system's capabilities. Users can easily integrate additional functionality to tailor the system to specific application needs.

The 8BVI0220HCD0.000-1 inverter module has a 22 A rating, supporting two-axis control with substantial load demands. It can deliver sufficient power to operate motors effectively, maintaining optimal performance under varying conditions. This module is suited for a wide range of industrial automation applications, where reliable and consistent power delivery is essential. It supports cold plate or pass-through mounting, ensuring compatibility with various operational environments. It features a DC bus connection with a 750 VDC voltage rating. This ensures a stable power supply to multiple components within the automation system.

The unit has a 24 VDC output with two separate outputs, each delivering 24 volts of direct current. This allows efficient powering of auxiliary devices, sensors, or control systems within the automation setup. Two outputs allow for flexibility in system design, enabling users to independently supply power to different components without additional power supply units. This inverter module supports flexible installation accommodating vertical and horizontal (face-up) mounting orientations. The unit features a compact lightweight design for easy handling and seamless installation into existing systems.

8BVI0220HCD8.000-1 Technical Specifications

Type:	ACOPOSmulti Inverter Module
Current Rating:	22 A
Voltage Rating:	High Voltage
Mounting Type:	Cold Plate or Feed-through
Number Of Axes:	2
Repair Service Price:	$1,065.00 USD
Repair Service Lead Time:	3 Weeks
Features:	Cold Plate or Feed-through mounting options

Frequently Asked Questions about 8BVI0220HCD8.000-1

Q: What is the maximum output current of the 8BVI0220HCD0.000-1?

A: The 8BVI0220HCD0.000-1 has a maximum output current rating of 22 A, suitable for high-performance two-axis applications.

Q: What is the continuous power consumption of the 8BVI0220HCD0.000-1?

A: The continuous power consumption of the 8BVI0220HCD0.000-1 is 32.37 kW, allowing it to handle substantial load demands efficiently.

Q: How does the 8BVI0220HCD0.000-1 ensure effective thermal management?

A: The 8BVI0220HCD0.000-1 inverter module supports cold plate and pass-through mounting options, which enhance heat dissipation to ensure optimal operating conditions during use.

Q: How many plug-in modules can be installed in the 8BVI0220HCD0.000-1?

A: The 8BVI0220HCD0.000-1 inverter module has two slots for ACOPOSmulti plug-in modules, allowing for system customization and additional functionality based on specific application needs.

Q: What is the nominal DC bus voltage of the 8BVI0220HCD0.000-1 inverter module?

A: The nominal DC bus voltage of the 8BVI0220HCD0.000-1 inverter module is 750 VDC, providing stable power supply and reliability for demanding applications.

Internal Product Review

‘‘The 8BVI0220HCD0.000-1 offers robust performance in automation systems that require an efficient two-axis motion control system. It is also optimized for seamless integration with existing systems and comes with multiple expansion slots for easy customization.’’
