4PP065.0351-P74

Name: 4PP065.0351-P74
Brand: B & R Automation
Price: 267 USD
Availability: InStock
Rating: 4.4 (12 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

In-Stock, Ships 3-5 Days

Current response time:

6 Minutes 51 Seconds

The 4PP065.0351-P74 is equipped with a 3.5\" QVGA color TFT display and resistive touch screen. Manufactured by B & R Automation, this device is part of the 4PP Power Panel Series, featuring a Geode LX800 32-bit x86 processor and IP65 front protection. It offers 2x USB ports and 1x ethernet and Powerlink connectivity.

Preparing your secure checkout page...

Description
Specs
FAQ

Product Description

The 4PP065.0351-P74 Power Panel by B&R Automation is a compact and versatile module featuring a 3.5-inch QVGA color TFT display with touch screen capability. It is suited for applications that require a user-friendly interface for display and control functions in automation processors. This model boasts high efficiency, running on a 32-bit Geode LX800 processor with a clock frequency of 500 MHz. It can handle data processing and control functions efficiently even in demanding environments making the panel suited to a wide range of application needs. The panel supports the Automation Runtime operating system, ensuring that it can be easily integrated into various automation systems.

The 4PP065.0351-P74 is set up to connect seamlessly with a wide range of peripherals and network devices. It features a CompactFlash slot, Ethernet 10/100, POWERLINK, and two USB ports. These interfaces provide users with versatile connectivity options to suit their specific requirements. The module features 128 MB of DRAM and 232 kB of SRAM, providing it with efficient memory for reliable performance. Users can easily expand the system memory via the CompactFlash slot to suit their application needs.

This panel is suited for a nominal voltage of 24 VDC. It can also tolerate fluctuations in voltage in the range of ±25%, making it adaptable to various industrial environments. It is rated for a nominal current of 0.45 A, allowing efficient energy usage. The panel comes equipped with a removable battery for ease of maintenance, It also features a real-time clock (RTC) with an accuracy of approximately 30 ppm. This clock is also battery-backed, ensuring it retains accurate time information even during power outages. The module has a front IP 65 and IP 20 rear protection, permitting use in tough industrial environments.

4PP065.0351-P74 Technical Specifications

Protection:	IP65 (front)
Processor:	Geode LX800, 32-bit x86
Clock Frequency:	500 MHz
Leds:	4 (CF Orange, Status Red/Green, EPL Red/Green, User Green)
Battery Type:	Renata 950 mAh Lithium ion
Touch Screen:	Resistive
Function Keys:	30
Dram:	128 MB
Sram:	232 kB
CompactFlash Slot:	Yes
Ethernet:	1x ETH 10/100
Powerlink:	1x POWERLINK
Usb:	2x USB

Frequently Asked Questions about 4PP065.0351-P74

Q: What is the display type of the 4PP065.0351-P74?

A: The 4PP065.0351-P74 features a 3.5-inch QVGA color TFT display with a touch screen, providing clear visuals and an intuitive user interface.

Q: What kind of battery does the 4PP065.0351-P74 use?

A: The 4PP065.0351-P74 uses a Renata battery with a capacity of 950 mAh, which provides reliable backup power for data retention. This battery is removable and accessible from the outside.

Q: What is the nominal voltage range for the 4PP065.0351-P74?

A: The 4PP065.0351-P74 operates at a nominal voltage of 24 VDC, with a tolerance of ±25%. This flexibility allows it to function effectively even with slight variations in voltage.

Q: What is the degree of protection for the 4PP065.0351-P74?

A: The 4PP065.0351-P74 has an IP20 rating for the back, while the front is rated IP65, ensuring protection against dust and moist conditions.

Q: Does the 4PP065.0351-P74 support external connections?

A: Yes, the 4PP065.0351-P74 features multiple connection options, including a CompactFlash slot, one Ethernet 10/100 port, one POWERLINK port, and two USB ports.

Internal Product Review

‘‘The 4PP065.0351-P74 is a user-friendly interface with a responsive touch screen, which significantly enhances operational efficiency. It offers flexible customization options to suit different user needs. However, it is not equipped with galvanic isolation which can be a concern in some settings. ’’
