Beckhoff

Beckhoff's A - Electric Cylinder Series are the ideal direct drives for linear applications that demand high process forces and speeds. These advanced actuators seamlessly blend the advantages of pneumatic technology, such as impressive force and compact dimensions, with the superior control and efficiency of servo-driven systems. The integrated mechanism, featuring precise roller bearings, ball screw, and guide, ensures a backlash-free, purely translatory motion, delivering exceptional performance and reliability. One of the key features of the A Series is its compatibility with existing pneumatic cylinder installations. The flange size of the electric cylinders is based on the ISO 15552 standard, and they feature bolting points on both sides, allowing for easy conversion from pneumatic to electric drive technology. This compatibility simplifies the transition process and enables machine builders and system integrators to leverage the benefits of electric actuation without the need for extensive modifications to their existing designs. In addition to the high-resolution, safe 24-bit multi-turn encoder, the A Series electric cylinders offer the advantages of One Cable Technology (OCT) and an electronic nameplate, streamlining the commissioning process and enabling seamless integration into the Beckhoff TwinSAFE solution for efficient machine safety implementation. The integrated anti-rotation device of the spindle further enhances the ready-to-use nature of these actuators, eliminating the need for additional mechanics.

The Beckhoff AL linear motor series is a versatile, high-performance family of direct-drive linear servomotors engineered for dynamic industrial motion applications​. It spans three standard widths (50, 80, and 130 mm) with a wide array of motor variants, providing peak forces from ~120 N up to 6,750 N and top speeds around 10–12 m/s to meet diverse application needs​. A key design feature is its modular coil concept: each motor is built from identical coil segments, allowing flexible length customization and creating a precisely symmetrical structure that simplifies mechanical integration with uniform mounting dimensions​; this balanced design also yields even force distribution and efficient cooling without hot spots for reliable continuous operation​. Optimized for smart manufacturing, an optional One Cable Technology (OCT) version consolidates power, feedback, and thermal sensor connections into a single cable, drastically simplifying wiring and commissioning via an electronic nameplate​; the motors also interface seamlessly with Beckhoff’s EtherCAT-based servo drive systems (AX5000/AX8000) without the need for extra hardware like connector boxes, enabling plug-and-play integration into advanced automation environments​. Overall, the AL series combines adaptability, efficiency, and reliability – from its cooling-optimized design to its integration-friendly features.

The Beckhoff AM Servo Motor Series is a versatile and highly capable range of synchronous servomotors that cater to a wide variety of industrial applications. The series encompasses several distinct product lines, each tailored to address specific needs and challenges. The AM8000 series, for instance, is characterized by its exceptional power density and compact design, making it suitable for applications that require high dynamics and speed. These motors are available in seven sizes with up to four stack lengths, providing a seamless power range from 0.2 to 129 Nm of standstill torque and speeds up to 12,000 rpm. The AM8300 series expands the portfolio with a modular motor series featuring integrated water cooling, allowing for an extremely high-power density of up to 40 kW within a compact footprint. This makes the AM8300 an ideal choice for applications with demanding thermal requirements. Additionally, the AM8500 series offers an increased rotor moment of inertia, catering to applications with stringent synchronism and control quality needs. For industries with strict hygiene standards, such as the food and packaging sectors, the AM8700 and AM8800 series provide solutions with anodized or stainless-steel housings, respectively. These motors combine the high-performance characteristics of the AM8000 series with enhanced cleaning capabilities and protection against aggressive media.

Beckhoff’s AMI series integrated drive motors unify a servomotor, drive electronics, and EtherCAT communication interface into a single compact unit​. This all-in-one design (supporting up to 400 W in the 48 V DC range) can be mounted directly on machines as an EtherCAT slave without any control cabinet or intermediate I/O stage​, significantly reducing wiring and machine footprint while enabling compact, flexible, and modular machine architectures​. The AMI drives also support standardized motion profiles such as the EtherCAT CiA 402 drive profile​ and offer optional TwinSAFE safety functions like STO (Safe Torque Off) and SS1 (Safe Stop 1) for integrated functional safety​. Mechanical versatility is provided via optional features such as holding brakes, shaft seals, and keyed shafts​, complemented by integrated absolute encoders (single-turn or battery-free multi-turn) for precise position feedback and standard M8 (EtherCAT) and M12 (power) connectors that ensure robust, industry-standard connectivity​. With its space-saving, networked design and smart features, the AMI series exemplifies an Industry 4.0 philosophy geared towards cabinet-free automation in smart manufacturing environments, delivering adaptable high-performance motion solutions across a wide range of industrial applications.

The Beckhoff AS Stepper Motor Series of stepper motors is a comprehensive product line that caters to a wide range of industrial automation requirements. These two-phase stepper motors are designed to bridge the gap between traditional stepper motors and high-performance servomotors, offering a versatile solution for applications that demand precise and reliable motion control. The series encompasses seven models, each with a stepper angle of 1.8 degrees, and a holding torque range from 0.8 to 8 Nm, ensuring that users can select the appropriate motor for their specific needs. One of the key features of the AS Stepper Motor Series is its industrial-grade design, which includes a higher IP54 protection rating, making the motors suitable for use in harsh environments. The motors also feature easy cabling thanks to the standardized, integrated M12 high-power screw-type connector for power and the robust M12 connector for the encoder. The torsion-proof, integrated encoder with 1024 increments per revolution, combined with the Beckhoff-supported vector control system, minimizes resonances and reduces the generation of heat and noise, providing servo-like operating characteristics. The AS Stepper Motor Series stepper motors are designed to be seamlessly integrated with Beckhoff's EtherCAT stepper motor terminals, such as the EL7037 (1.5 A) and EL7047 (5 A), as well as the EL7062 two-channel stepper motor terminal, which supports the 5 V TTL encoder. This integration simplifies the commissioning process and allows users to leverage the powerful TwinCAT automation software for easy axis layout and configuration.

The Beckhoff AT XTS Starter Series (AT Series) is a comprehensive package designed to provide users with an accessible introduction to the world of eXtended Transport System (XTS) technology. At the core of the series is a fully assembled and pre-configured XTS system featuring a range of versatile motor modules that can be combined in various geometries to create both open and closed product transport paths. Precision-engineered guide rails and movers ensure smooth and accurate motion along the defined paths. A key advantage of the AT Series is that it includes an integrated Industrial PC control system with the necessary interfaces and processing capabilities. The PC comes preloaded with Beckhoff's TwinCAT NC PTP and XTS function packages, allowing for seamless integration within the Beckhoff automation ecosystem. The entire pre-assembled and pre-wired system is housed within a control cabinet. This provides users with a turnkey XTS solution that can be easily set up to allow for immediate operation and experimentation with programming customized motion profiles. With all essential components combined into one comprehensive package, the AT Series lowers the barrier to entry for exploring and applying the innovative capabilities of eXtended Transport Systems in product handling and movement applications.

Beckhoff's AX Digital Servo Drive Series exemplifies the company's drive for cutting-edge motion control solutions. At the core are integrated servo drives like the AX5000 family featuring 62.5μs control cycles for exceptional dynamic response and precision. Seamlessly interfacing with Beckhoff PC-based systems via high-speed EtherCAT, optimal synchronization is achieved. The Series accommodates a wide variety of motor types including synchronous, linear, torque and asynchronous variants, as well as multi-feedback interfaces for compatibility with diverse motor configurations. Further flexibility is offered through cost-optimized two-channel drives that enable independent dual-motor operation from a single unit. Complemented by pre-assembled cabling, filters and installation aids, the drives integrate smoothly into complex motion applications. These innovative, high-performance servo solutions deliver dynamic control for industries as diverse as machine tools, semiconductor assembly and robotics. With flexible, scalable options agnostic to specific motor types, the AX Series represents Beckhoff's commitment to customized, future-proofed motion control ideal for the modern industrial automation landscape.

The Beckhoff BC Bus Terminal Series (BT Series) forms a fundamental component of Beckhoff's open automation technology. The series provides a comprehensive portfolio of more than 1,000 modular Bus Terminals that allow for fine-granular composition of I/O channels for different signal types, including digital, analog, and specialized terminals. A key strength of the BT Series is its fieldbus-neutral communication capabilities. Via Bus Couplers, the terminals can interface directly with more than 30 fieldbus and Industrial Ethernet systems without requiring additional bus interfaces. This flexibility enhances integration across subsystems and control architectures. The series also offers various connection technologies to optimize applications. Designed for enhanced economic efficiencies, the BT Series components fit standard DIN rails and terminal boxes, with automatic contact made through simple vertical insertion. This streamlines planning, installation, commissioning and maintenance tasks. Suitable for a wide range of industries, the versatile and cost-effective BT Series supports precise composition of I/O configurations to meet application and system communication requirements.

Beckhoff's comprehensive BK EtherCAT Bus Coupler Series is designed to seamlessly bridge EtherCAT communication at the field level with connected Bus Terminals. Engineered for robustness, couplers within the Series feature dual RJ45 sockets for flexible integration into the EtherCAT network while accommodating additional devices on the same segment. Readily supporting up to 64 terminals directly and 255 via K-bus extension, the couplers provide ample scalability for growing automation needs. Optimized for high-speed 100Mbit/s data transfer, critical process information is transmitted efficiently to enable real-time control and monitoring. Featuring advanced diagnostics and versatile configuration, the Series empowers easy management of complex systems. This comprehensive fieldbus interface facilitates smooth implementation and expansion of diverse automation applications. With reliable and scalable EtherCAT connectivity, the BK Series represents Beckhoff's dedication to optimized industrial networking solutions. It facilitates integrated and future-proofed harnessing of EtherCAT's benefits across many industries.

The Beckhoff BX Bus Terminal Controller Series are designed to provide enhanced functionality for distributed signal processing and standalone applications. Distinguishing the BX series from the simpler BC series is significantly larger memory capacity, with 256 kBytes each of program and data memory allowing more complex and large programs. This expanded memory enables greater local data management, suiting decentralized processing and decision-making. In addition, the BX series boasts expanded interfaces compared to its BC counterparts, featuring two configurable serial ports and an Ethernet port for connectivity to serial and Ethernet-based devices and protocols. The integrated real-time clock also enables applications where date and time play important roles. These distinguishing features coupled with the versatility of Beckhoff’s bus terminal I/O system and TwinCAT automation software make the BX series well-equipped for a diverse range of control solutions. With memory and connectivity bridging Beckhoff’s BC and CX lines, the BX series is optimized for tasks including automated control of manufacturing machinery, building automation processes, and autonomous control and monitoring in various industrial environments demanding distributed processing capabilities.
